Brief Introduction

Apera Instruments 2401T-F Conductivity Electrode is featured with a proprietary platinum black sensor
for accurate readings in a wide conductivity range up to 200 mS/cm, along with a built-in temperature
sensor for automatic temperature compensation.

Technical Specifications

Range
Housing
Constant
Connector
Cable length
Dimension
Temperature sensor
Operating temperature

How to Install the Electrode

1. Find the conductivity BNC socket (where it shows Cond) on the conductivity meter; Open the
rubber cap; Insert the BNC connector of the electrode to the BNC socket while twisting clockwise
until it's locked.
2. Find the RCA socket (where it shows temp.) on the pH meter; Open the rubber cap; Insert the
black RCA connector of the electrode to the RCA socket directly.
3. After connecting the new electrode to your meter, adjust the meter's constant K to 1.0 according
to the instruction of your meter's manual. Then perform a 2 to 3-point calibration to ensure the
accuracy.

How to Use the Electrode

1. There is a proper amount of deionized water in the cap on top of the electrode. The conductivity
sensor is soaked in it to keep its sensitivity.
2401T-F Conductivity/Temp. Electrode
User Manual
0 to 200 mS/cm, 32 to 122°F (0 to 50°C)
Lead-free Glass
K=1.0
BNC/RCA
3 Ft
ø12*145 mm
30KΩ thermistor
32 to 176°F (0 - 80°C)
