Summary of Contents for Safeline TTR

  • Page 1 TTR manual Communications system Innovation brought to you from Tyresö Sweden www.safeline-group.com 12.2021 © 2021 SafeLine and all the SafeLine products and SafeLine TTR v.2.2.0 EN accessories are copyrighted by law.
  • Page 2 Acoustic emergency signal output: 12 VDC max 0.5A. Inputs: 10-30 Volts; 5 mA. Optically isolated. Pictogram outputs: Max 200mA, 12VDC. Size: 181,5 x 171,2 x 71 mm (L x W x H). Weight: 1,5kg This product is intended for use in EMEA countries. SafeLine TTR v.2.2.0 EN...
  • Page 3: Table Of Contents

    Remote Config. with telephone first step Remote Config. with telephone second step On-site configuration with telephone Configuration example Configuration codes table Operation Calling with SafeLine TTR Intercom between machine room & car/pit/Top of car Emergency calling process Service Battery function Trouble shooting Declaration of conformity SafeLine TTR v.2.2.0 EN...
  • Page 4: General Information

    If it is to be used It is extremely important that for any other purpose, SafeLine these installation instructions must be contacted in advance. are made available at all times...
  • Page 5: Introduction

    TTR board (not autodetect). TTR and other emergen- • Install jumpers on the TTR board, so they stand as the unit cy-alarm telephones. which is replaced (same jumper names). • Remember to attach the unit, and tighten the screws in the lid to avoid the device to “rattle”.
  • Page 6: Component List

    Component list 3a 3b 3c SafeLine TTR v.2.2.0 EN...
  • Page 7 Jumpers for emergency button Selects NO/NC for the emergency button Jumpers for pictogram, emergency light and sounder The outputs from the SafeLine TTR can be configured by use of the jumpers J8 and J9 to activate pictograms emergency light and sounder switch.
  • Page 8 Extra station card GSM Antenna Terminal or RJ12 connector for PSTN line. Internal connection of PSTN line. GSM antenna connection, SMA SIM-card holder Volume controls For the extra remotes. Turn right to increase the volume. Terminals For the extra remotes. GSM antenna SafeLine TTR v.2.2.0 EN...
  • Page 9: Installation

    >>1.5 m >>1.5 m 0,1m ² >>1.5 m Unplug the main power and battery before performing any changes. To avoid GSM interference: Place the main unit, the stations and the GSM antenna more than 1.5 meters apart. SafeLine TTR v.2.2.0 EN...
  • Page 10: Mounting Interface Boards

    Mounting GSM/4G interface boards PSTN Extra station card SafeLine TTR v.2.2.0 EN...
  • Page 11: Wiring Diagram, Emergency Bell And Light

    Jumper settings With the jumpers “J8” and J9 in the position as shown left, the SafeLine TTR can supply backup power for emergency light in the lift car. The jumpers “J1”, “J2” and “J5” shall be set as shown left and shall not be changed.
  • Page 12: Wiring Diagram, Emergency Bell And Pictograms

    Jumper settings With the jumpers “J8” and J9 in the position as shown left, the SafeLine TTR can operate pictograms according to EN 81-28 / EN 81-70. The jumpers “J1”, “J2” and “J5” shall be set as shown left and shall not be changed.
  • Page 13: Wiring Diagram, Emergency Light And Pictograms

    Emg.light - Jumper settings With the jumpers “J8” and J9 in the position as shown left, the SafeLine TTR can sypply backup power for emergency light in the lift car. The SafeLine TTR can also operate pictograms according to EN 81-28 / EN 81-70.
  • Page 14: Wiring Diagram, Extra Station Card

    Grey Orange Black Wiring diagram PSTN Line (max 9 units) Connect the telephone line in parallel according to the picture above. It’s possible to connect up to 9 SafeLine TTR units to the same telephone line. SafeLine TTR v.2.2.0 EN...
  • Page 15: Network Services

    Make a call from your phone to verify that the SIM card is active, before you move it to the SafeLine TTR. Also make a call to SafeLine TTR after insertion to check that it is possible to get a proper connection.
  • Page 16: Led Indication

    Resets an active alarm. Aborts calls in progress. Signal strength 1 2 3 LED3 LED2 = 100% LED1 >= 85% Reset >= 70% >= 55% >= 30%* >= 15% >= 0% *Minimum signal strenght for using GSM Interface SafeLine TTR v.2.2.0 EN...
  • Page 17 The Yellow Pictogram LED, is lit The Green pictogram LED turns as soon as the alarm button is on as soon as the SafeLine unit pressed longer than the set delay. detects a responding voice. The LED is turned off when the call is terminated.
  • Page 18: Test Procedure After Installation

    LED 1 turns green. No reaction LED 3 flashes green Connect a telephone to the RJ12 connector on Check mains power the front of the SafeLine Lift the handset Internal dial tone No tone Check the handset Press Phone line dial tone...
  • Page 19: Configuration

    Pro software to a laptop computer from safeline-group.com and make sure you have the required programming cable. Connect the computer to the unit and start configuration using the software. Configuration of the unit can also be done remotely using SafeLine ProLink (*PROLINK). CONNECTable...
  • Page 20 7 8 9 Remote configuration with telephone. For remote configuration, you can use any PSTN tone dial phone. Dial the phone number of the SafeLine. Enter the function codes on the phone keypad to start configuration (password has to be entered). SafeLine TTR v.2.2.0 EN...
  • Page 21: Remote Config. With Telephone First Step

    Remote Config. In order to remotely configure the SafeLine, the unit must first be put into configuration mode via voice communication mode. To with telephone enter voice communication mode, refer to the instructions below. first step After the unit has been set in voice communication mode, follow the steps for remote configuration on the next page.
  • Page 22: Remote Config. With Telephone Second Step

    *00*# Enter code and data, eg: 2 short beeps *11*012341234# Call disconnected or 2 short beeps? end of configuration. Invalid input (one long tone) SafeLine will restart Last code has to with new settings be reentered SafeLine TTR v.2.2.0 EN...
  • Page 23: On-Site Configuration With Telephone

    Enter code and data, eg: 2 short beeps *11*012341234# Call disconnected or 2 short beeps end of configuration. Invalid input (one long tone) SafeLine will restart Last code has to with the new settings be reentered SafeLine TTR v.2.2.0 EN...
  • Page 24: Configuration Example

    Refer to the “Configuration methodes” chapter before reading this example, to know how to get started. example The example will assign the following settings to the SafeLine SL6: • ID code for P100 protocol to 12345677. • First phone number to emergency call centre to 42345688.
  • Page 25: Configuration Codes Table

    Change this only if your alarm operator is using any of the mentioned protocols. Call type 4th number *24* Call type LMS number *30* LMS(Lift Monitoring System) call type 0 = P100 3 = CPC (Only battery alarm) SafeLine TTR v.2.2.0 EN...
  • Page 26 Example of message: This is an alarm from the Record alarm message from *54* ”Speak” # lift on 5th avenue. Lift pit to alarm central To hear the quality of the message, press “1”. To terminate the call press “#”. SafeLine TTR v.2.2.0 EN...
  • Page 27 (Default = 02) Unit number *82* Program Unit number [0-9], when units share phone line. Detect dial tone *83* 0 = Off 1 = On (Default) Set to off if SafeLine has problem to detect the dial tone. SafeLine TTR v.2.2.0 EN...
  • Page 28 Relay 2 will be activated for 5 seconds when DTMF “9” is pressed. 3 = Manual - ECF Relay 1 will be activated when set delay reached. Relay 1 will be deactivated when the reset button is pressed. SafeLine TTR v.2.2.0 EN...
  • Page 29 ”*”. To listen press ”7”. Go back to automatic mode press ”4”. The call is terminated by pressing ”#”. It is possible to enter manual voice switching mode although the unit is programmed as automatic by pres- sing ”*”. No ascending tones will be heard. SafeLine TTR v.2.2.0 EN...
  • Page 30: Operation

    Operation Calling with The TTR can call in the following ways: SafeLine TTR Intercom between machine room and car/pit/car-top, see below. Make calls with a normal fixed phone line and through GSM. Emergency calls to numbers at the press of the alarm button.
  • Page 31: Intercom Between Machine Room & Car/Pit/Top Of Car

    Press 2 to call the car-top. 4 5 6 7 8 9 Press 1 to call the lift car. 4 5 6 7 8 9 Press 3 to call the lift pit. 4 5 6 7 8 9 SafeLine TTR v.2.2.0 EN...
  • Page 32: Emergency Calling Process

    3 times. This adds up to the 12 call limit. Calling 1 phone number. Answer? Calling 2 phone number. Answer? Calling 3 phone number. Answer? Calling 4 phone number. Answer? Alarm operator made connection Emergency call completed SafeLine TTR v.2.2.0 EN...
  • Page 33: Service

    Testing the battery alarm: • Unplug the battery contact during the battery status check. • The SafeLine TTR will now emit a battery alarm and LED 2 and the battery alarm relay will be activated (if so configured). Cancelling the battery test: •...
  • Page 34: Trouble Shooting

    The unit can not make an alarm call. At least one phone number (and one ID code if using data identifi- cation) must be programmed to enable making a call from the unit. Refer to the parameter list (*11*). SafeLine TTR v.2.2.0 EN...
  • Page 35: Declaration Of Conformity

    EU Declaration of Conformity TTR V2.02...
