    ASSEMBLY INSTRUCTIONS ARLO-4 DRAWER CHEST IMPORTANT : READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR ARLO-4 DRAWER CHEST. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. ASSEMBLY: Assembly should be carried out with this item laying flat, not standing upright.
  • Page 3 Vendor: S000350 Page of 6...
  • Page 4 Vendor: S000350 Parts List Hardware List ( BOX 1 ) Part Descripion Part Description Top panel Cam lock Bottom panel Minifix screw Side panel ( Left ) Plastic cap Side panel ( Right ) M8 x 30mm Wood Dowel Back bone M6 x 50mm CSK Cap Wood screw Back panel Allen key M4...
  • Page 5 Vendor: S000350 Step 2: Attach top panel (1) to side panel (3), (4) and back bone (5) using hardware A1 and A2 with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. A3 x 6 Step 3: Attach bottom panel (2) to side panel (3), (4) and back bone (5) using hardware C and D.
  • Page 6 Vendor: S000350 Step 4: Attach back panel (6) to entire body using hardware J with a hammer (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. J x 22 Step 5: Attach hardware N to bottom panel (2) using hardware F with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
  • Page 7 Vendor: S000350 Step 6: Attach the Drawer Side (9) to the Drawer Front (7) and Drawer Back (8) using hardware H. Then attach the Drawer Bottom (10) using hardware J. Secondly attach the Drawer Bone (11) to the Drawer Bottom (10) using hardware G then attach the Drawer Slides (M2) to the Drawer Bottom (10) using hardware F.
  • Page 8 Ensure the head of any screw used has a diameter greater than the mounting hole and the fixing is safe and secure before use. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product.
