1 General
1.1 About this manual
This manual belongs to an Invacare accessory and it contains important
information about handling and assembly. In order to ensure safety
when using the product, read the user manual of the related product
carefully and follow the safety instructions.
Symbols in this manual
In this user manual, warnings are indicated by symbols. The warning
symbols are accompanied by a heading that indicates the severity of
the danger.
WARNING
Indicates a hazardous situation that could result in
serious injury or death if it is not avoided.
CAUTION
Indicates a hazardous situation that could result in
minor or slight injury if it is not avoided.
IMPORTANT
Indicates a hazardous situation that could result in
damage to property if it is not avoided.
Tips and Recommendations
Gives useful tips, recommendations and information
for efficient, trouble-free use.
2 Assembly
2.1 General
When this side rail height extender is used, the allowed mattress
thickness can be increased by 15 cm. See user manual for your bed
and side rail for correct mattress sizes.
1538345-0125 Side rail height extender for Line side rails, Figure 1.
1538420-0125 Side rail height extender for Britt V side rails, Figure 2.
DEALER: Keep this manual.
The procedures in this manual MUST be performed by a qualified technician.
Side rail height extender
en Bed accessory for Britt and Line Side rail
Service Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
da Sengetilbehør til Britt og Line sengehest
Servicemanual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
de Bettzubehör für Seitengitter Britt und Line
Service Handbuch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
es Accesorio de cama para barandillas Britt y Line
Manual de servicio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Accessoire de lit pour la barrière Britt et Line
fr
Manuel de maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
it Accessorio per letto per sponda laterale Britt e Line
Manuale per la manutenzione . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
nl Bedaccessoire voor het Britt- en Line-zijhekken
Servicehandleiding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
nn Sengetilbehør for sengegrindene Britt og Line
Servicehåndbok. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
IenI
Acessório de cama para a guarda lateral Britt e Line
pt
Manual de assistência. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
sv Sängtillbehör för Britt och Line sänggrind
Servicemanual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
WARNING!
Risk of falling out of bed if the side rail height
extender loosens/falls off leading to body injuries
or death.
– Make sure the correct side rail height extender is
used (shape of attachments must match shape of side
rail). See label; Figure 1 , Figure 2, on your product to
determine which side rail height extender to use for
your specific side rail.
– Make sure that the side rail height extender is properly
attached (finger screws tightened).
Figure 1
.
Figure 2
