Medeli MZ520 Setup Manual

Setup Guide

Check the included items

CYMBAL PAD
Hi-hat Crash Ride
KICK PAD KICK PEDAL
Kick Pad Kick Pedal

Assemble the Drum Stand

Step
Center Pipe [ G ]
Center Pipe [ E ]
Pillar Pillar
[ A ] [ B ]
DRUM PAD
Tom 1 / Tom 2 / Tom 3 Snare
( x 3 )
MODULE
Beater Drum Module Connection Cable
Step
Side Pipe [ F ]
Side Pipe [ I ]
Pillar
[ C ]
WARNING:
•
Drum key may pinch your fingers. Be careful when adjusting clamps with drum key.
•
Mind the sharp ends, such as pipe ends and screw ends. They may injure your fingers.
PEDAL DRUM STAND
Pedal ( Hi-hat )
MINI PAD
Pillar Pillar Pillar Pillar
[ A ] [ B ] [ C ] [ D ]
Mini Pad ( x 2 )

Attach the Pad, Hi-hat and Cymbal Holders

Side Pipe [ H ]
Pillar
[ D ]
ACCESSORIES
Center Pipe [ E ]
L-Rod Holder
Center Pipe [ F ]
Hi-hat Holder
Side Pipe [ G ]
Cable Clip
Side Pipe [ H ]
Cymbal Holder x 2
Side Pipe [ I ] Owner's
Manual
Cymbal Holder Cymbal Holder
Hi-hat Holder
Drum Key Drumsticks
Hand Bolt AC Adaptor
Setup Guide
( This document )
L-Rod Holder
