Security Brands Antenna 300 Instructions

I N S T R U C T I O N S

IN THE BOX

Make sure you have
everything shown here.

SETUP

1. Mount antenna mounting bracket securely where
desired using included Tek screws.
NOTE: Typically the mounting bracket and
antenna will be mounted high on the side
of the gate operator enclosure to clear the
interference caused by the metal enclosure.
2. Drill hole (3/4-inch) in gate operator enclosure
near antenna mounting location to be used as
pass-through for coaxial cable.
NOTE: Only drill this hole if necessary. If you
have some other means of passing the coaxial
cable through (or into) the enclosure effectively
without damaging the cable or enclosure, then
use that method.
ANTENNA 300
Antenna 15-foot Coaxial Cable
1 of 2
Model 14-ANT300
Antenna Bracket with
Coaxial Connector
Tek Screw
( 2x )
