- Page 2 PAGE STAGE Upper left engine block Left side of the engine block Upper right engine block Front cover of the engine block and the pulleys Right side of the engine block Published in the UK by De Agostini UK Ltd, Royds Withy King, 65 Carter Lane, London EC4V 5EQ. Published in the USA by De Agostini Publishing USA, Inc., 299 Park Avenue •...
- Page 3 Faros y cap Stage 76: Upper left Ford GT engine block Your parts 76-A Left cylinder head 76-B Upper left engine block 76-C FP01 2.3 mm x 4 mm Ø 3.8 mm screws 76-A 76-B FP01 Note: The parts may differ slightly from those in the photos.
- Page 4 STEP BY STEP STEP 76-1 Gros Ergot ergot Position the left cylinder 76-A head (76A) over the upper left engine block. The cylinder head has two different-sized linchpins which must be aligned 76-B with the corresponding holes in the block. STEP 76-2 Attach the left cylinder...
- Page 5 Ford GT STAGE COMPLETE...
- Page 6 Faros y cap Stage 77: Left side of the STEP BY STEP engine block Your parts 77-A Left side of the engine block 77-B Hydraulic brake hose 77-C FP02 1,8 x 4 mm Ø 3 mm screws 77-A 77-B FP02...
- Page 7 Ford GT STEP 77-1 Square linchpin Get the piece you assembled 76-B in the previous pack. Attach the upper left engine block (76B) to the left side of the engine block (77A). To do this, insert the square linchpin 77-A...
- Page 8 STEP BY STEP STEP 77-4 Slide the free end of the hydraulic brake hose (77B) onto the linchpin on the outside Linchpin of the rear left brake 77-B caliper (70D). Make 70-D sure the hose fully covers the linchpin. STAGE COMPLETE...
- Page 9 Stage 78: Upper right Ford GT engine block Your parts 78-A Right cylinder head 78-B Upper right engine block 78-C Oil filler tube 78-D FP01 2.3 x 4 mm Ø 3.8 mm screws 78-A 78-B 78-C FP01...
- Page 10 STEP BY STEP STEP 78-1 Position the oil filler tube 78-C (78C) over the right cylinder head (78A). Insert the tube into the corresponding hole, 78-A then turn the cylinder head over and secure the tube with a FP01 screw. FP01 STEP 78-2...
- Page 11 Ford GT STAGE COMPLETE Note : La photo correspond à un prototype.
- Page 12 Faros y cap Stage 79: Front cover of the STEP BY STEP engine block and the pulleys Your parts 79-A 79-A Oil sump 79-B Engine block front cover 79-C Pulley mechanism 79-D Alternator 79-E Manifolds 79-F FP01 screws 2.3 x 4 mm Ø 3.8 mm 79-G FP07 screws 2.3 x 4 mm Ø...
- Page 13 Ford GT STEP 79-1 Linchpins Position the alternator (79D) 79-D over the pulley mechanism (79C). Insert the two linchpins on the alternator into the holes in the 79-C pulley mechanism, as shown. After attaching the alternator, secure it with one FP01 screw.
- Page 14 STEP BY STEP Linchpins 79-B 77-A 62-A STEP 79-4 Get the left side of the engine block (77A). Put the piece you just assembled in the correct position. Insert the linchpin into the hole in the right side of the engine block, as shown in the photo. STEP 79-5 After attaching the front cover...
- Page 15 Ford GT STEP 79-6 Insert two FP07 screws into the two protrusions on the back of the oil sump (79A). Do not over tighten the screws as they will be used to attach the oil sump to the FP07 engine block.
- Page 16 Faros y cap Stage 80: Partie droite STEP BY STEP du bloc moteur Your parts 80-A Right side of the engine block 80-B Hydraulic brake hose 80-C FP02 screws 1.8 x 4 mm Ø 3 mm 80-D FD08 screws 2.3 x 4 mm Ø 3.8 mm 80-A 80-B FP02...
- Page 17 Ford GT STEP 80-1 Ergot Ergot 78-B 78-B carré carré Get the piece you assembled in the previous pack. Attach the upper right engine block (78B) to the right side of the engine block (80A). To do this, insert the square linchpin...
- Page 18 STEP BY STEP STEP 80-4 Slide the free end of the hydraulic brake hose (80B) onto the linchpin 66-D on the outside of the brake caliper (66D) you assembled together with the rear right wheel. 80-B Make sure the hose fully Ergot covers the linchpin.
- Page 19 Ford GT STEP 80-7 Slide the right side of the engine block (80A) onto the tab on the back of the right side of the transmission case (61A) and onto the two FP07 screws in the oil sump (79A). Insert the two linchpins on the right engine block into the holes in the left side of the engine block (77A).
