- Page 1 pack pack...
-
Page 2: Mounting The Pedals
Pack 13 Editorial by: Milanoedit srl, milanoedit.com Translation by: TperTradurre Picture credits: NBCUniversal Archive ©️ 2019 Universal City Studios LLC. Fast & Furious and all related marks and characters are trademarks Stage 51 and copyrights of Universal Studios. Mounting the pedals All Rights Reserved. - Page 3 MOUNTING MOUNTING STAGE STAGE THE PEDALS THE PEDALS In this assembly session you will attach the pedals to the inside of your model’s cockpit. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE 51A Pedal cover panel 51E Brake light switch bracket 51B Clutch pedal 51F Accelerator pedal...
- Page 4 STAGE 51 STAGE 51 51.1 the wiring and switch for the brake light 47A attached to front section of the chassis 21A. Pull out the part of the wiring with the switch, and disconnect the end from the connector that joins it to the section of wiring attached to the chassis. 51.2 nsert the brake light switch 47A...
- Page 5 STAGE 51 STAGE 51 51.3 osition the switch bracket 51E by aligning the two mounting holes with the corresponding holes in the pedal cover panel 51A. Ensure that the movement of the switch button is not hindered by the bracket. Then secure the bracket with two type AP screws.
- Page 6 STAGE 51 STAGE 51 51.6 ow you can attach the pedal cover panel 51A to the floor pan 48A. Secure it with four type CP screws. STAGE 51 FINAL RESULT You have now attached the foot pedals to the floor pan.
- Page 7 ASSEMBLING ASSEMBLING STAGE STAGE THE FLOOR THE FLOOR In this assembly session you will attach the front left and front right floor panels to your model’s floor pan. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE 52A Front left floor panel CP Screws 2×5 mm (x 5)* 52B Front right floor panel...
- Page 8 STAGE 52 STAGE 52 52.1 the front left floor panel 52A onto the floor pan 48A, aligning the two mounting holes. Secure by inserting two type CP screws into these holes. 52.2 ePeat on the right-hand side, positioning the front right floor panel 52B in the correct place. Again, secure the piece with two type CP screws.
- Page 9 STAGE 52 STAGE 52 52.3 the floor pan 48A over and align the six mounting holes in the rear floor panel 52C. Insert two type HP screws into the holes indicated in the illustration. 52.4 o secure the rear floor panel 52C, insert four type HP screws into the remaining mounting holes.
- Page 10 STAGE 52 STAGE 52 AN OVERVIEW In the illustration you can see the floor pan now it has been completed with the pieces that came with this stage. The floor pan will be attached to the middle section of the chassis, and it is the anchorage point for various pieces, such as the pedals, the gear lever, the fire extinguisher and, of course, the seats.
- Page 11 ASSEMBLING ASSEMBLING STAGE STAGE THE SEAT (I) THE SEAT (I) In this assembly session you will attach the backrest and the seat belt to the seat. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE 53A Seat 53C Seat belt 53B Backrest...
- Page 12 STAGE 53 STAGE 53 53.1 the narrower buckle of the seat belt 53C into nsert the slot on the left side of the seat 53A. Slide the belt through the slot, stopping before the other buckle passes through it. 53.2 the back of the seat, insert the narrowest buckle on the seat belt through the slot located on the right-hand side.
-
Page 13: Safety First
STAGE 53 STAGE 53 53.3 the backrest 53B to the seat 53A. The linchpins in the middle of the backrest 53B must be positioned below the two hollow tabs on the seat 53A, as shown in the illustration. SAFETY FIRST After joining the backrest and the seat, pull the two ends of the seat belt so that they are approximately the same length. - Page 14 STAGE 53 STAGE 53 53.4 the backrest 53B to the seat o secure 53A use two type IP screws. STAGE 53 FINAL RESULT You have now assembled the seat and attached the seat belt.
- Page 15 ASSEMBLING THE ASSEMBLING THE STAGE STAGE SEAT (II) SEAT (II) In this assembly session you will attach the backrest and the seat belt to the seat. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE 54A Bottom section of the seat IP Screws 1.7×4x5 mm (x 3)* 54B Backrest cover...
- Page 16 STAGE 54 STAGE 54 54.1 et the seat you assembled in the last assembly session. Align the backrest cover 54B with the backrest 53C. Secure the two pieces with four type AP screws. 54.2 the seat base 54C to the seat, making sure that the two linchpins shown in the image are below the tab on the bottom section of the seat 53A.
- Page 17 STAGE 54 STAGE 54 54.4 the bottom section of the seat 54A to the seat. Secure with four type AP screws. 54.5 ttach the completed seat to the guides on the floor pan 48A, making sure that the two small linchpins on the bottom of the seat slide into the corresponding mounting holes.
- Page 18 STAGE 54 STAGE 54 54.6 the floor pan over and secure the seat with two type JP screws. STAGE 54 FINAL RESULT You have now completed the seat and attached it to the floor pan of your model car.
- Page 19 ASSEMBLING ASSEMBLING STAGE STAGE THE DASHBOARD (I) THE DASHBOARD (I) In this assembly session you will assemble the dashboard of your model car. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE 55A Dashboard 55E Switches (x 2) 55B Instrument panel 55F Ignition switch AP Screws 1.7×4 mm (x 5)*...
- Page 20 STAGE 55 STAGE 55 55.1 the instrument cluster 55C and the instrument panel 55B, exactly as shown in the illustrations. 55.2 rom the back side of the instrument panel 55B, insert the two switches 55E, facing the same way as those in the illustration, into the holes on the left, and the ignition switch 55F into the hole on the right.
- Page 21 STAGE 55 STAGE 55 55.4 the switch on the sound wiring 46B into the rectangular nsert housing closest to the end of the instrument panel 55B. Then insert the plug of the wiring for the lights 46C into the other rectangular housing in the instrument panel.
- Page 22 STAGE 55 STAGE 55 55.7 lign the tabs on the dashboard 55A with the small linchpins at the top of the instrument panel 55B. Secure all the pieces with two type AP screws. STAGE 55 FINAL RESULT You have now completed the dashboard and instrument panel of your model car.
