Centipede 2
Temperature Control System
Instruction Manual for Remote
User Communications
Read and understand this manual before operating
or servicing this temperature control system.
Failure to understand how to safely operate these
controllers could result in an accident causing
serious injury or death. Only qualified personnel
should operate or service these controllers.
®
Module™
Centipede 2® Module™ Temperature Control System

Table of Contents

Setting Up HyperTerminal Thru Serial port (RS232) .......................................................... 3
Log-in Instructions for User Interface .................................................................................. 5
Operating Instructions: ........................................................................................................ 5
User Interface Command List ............................................................................................. 6
Detect and Assign Control Zone IDs .......................................................................... 7
Enumerate Control Zone IDs .............................................................................. 7
Detect and View Control Zones .......................................................................... 7
Reset Zone IDs and Settings .............................................................................. 7
Manually Set an Individual Zone ID .................................................................... 8
Manually Set Multiple Zone IDs .......................................................................... 8
Reload Default Parameters ........................................................................................ 8
Program Temperature Control Zones ......................................................................... 9
Read / View Status of Temperature Control Zones .................................................. 10
Dump Command (Data Logging) .............................................................................. 10
Setting Alarm Relay - Latching Alarm Feature ......................................................... 11
Alarm Relay Summary Table ............................................................................ 11
Understanding the Message Status Codes .............................................................. 12
Normal Conditions Status Codes ..................................................................... 12
Locate Module/Zone ID Mode Enabled Status Codes ..................................... 12
Operator Interface Set-up ......................................................................................... 13
Time and Date Set-up ....................................................................................... 13
Password Change ............................................................................................ 14
Communication Mode Set-up ........................................................................... 14
Modbus RTU Protocol Set-up ........................................................................... 14
TCP/IP Set-up ........................................................................................................... 15
Locate Zone ID (Orange LED) .................................................................................. 16
Operator Interface Reset .......................................................................................... 17
Exit Session .............................................................................................................. 17
Appendix A: Centipede 2® Operator Interface Register Definitions ................................. 18
Appendix B: Centipede 2® Control Zone Register Definitions ......................................... 19
(Hexidemical to Binary Conversion) ................................................................................. 22
Trouble Shooting: Status Register Definitions .................................................................. 23
Contact Information .......................................................................................................... 24
®
BriskHeat
Corporation. All rights reserved
2
