- Page 1 LED SEMI COMMERCIAL MONITOR Tech Support #833-574-9124(Option2) info@wboxtech.com 0E-32MON720P（HD） 0E-43MON1080（FHD）...
-
Page 2: Table Of Contents
Contents Contents ............................1 Safety ............................1 Cautions............................3 FCC RF Interference Statement ..................4 Connections ..........................5 Controls & Menu Operation ....................6 Mounting Guide ........................ 11 Accessories ..........................12 Power Indicator / Modes of Operation ................12 Dimensions ..........................13 Specifications ........................ - Page 3 D. If batteries are used, please dispose of all batteries as per local regulations. E. Use the monitor in indoor environments as per the temperature and humidity specs. 8. The monitor should be operated from a power source indicated on the rear of the monitor. 9.
-
Page 4: Cautions
Cautions CAUTION TO SERVICE PERSONNEL POWER SUPPLY CORD IS USED AS MAIN POWER DISCONNECT DEVICE IN THIS PRODUCT. UNPLUG THIS PRODUCT FROM THE WALL OUTLET BEFORE REMOVING THE BACK COVER AND SERVICING. 1. Never open the monitor case Only specially qualified personnel should open the case. No user serviceable parts inside. 2. -
Page 5: Fcc Rf Interference Statement
FCC RF Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 6: Connections
Connection Back View of Monitor Connector panel is located on the underside of the case rear projection, just above the stand. 0E-32MON720P AC IN HDMI1 HDMI2 HDMI3 CO-AXIAL OUT Detailed View of the Connector Panel Only use a properly, AUDIO IN VIDEO IN L IN... -
Page 7: Controls & Menu Operation
(POWER) button “ ” 0E-32MON720P ●Press the button to turn ON or turn OFF the monitor. Input Source B. (VOL+) button ●Press the button,volume increase. - Page 8 E. (CH-) button ●Press the button to scroll the cursor to desired function. Press the button to decrease the value of selected function in sub OSD menu. F. (SOURCE) button Press the button to display all the signal channel menus. When Main menu display as confirmation key during the OSD operation.
- Page 9 SOUND Menu Sound Mode: press the right or left key to Sound Mode Standard adjust the sound mode, it can change to : Treble Bass SOUND Balance user / music / movie / sports / standard. Auto Volume Surround Sound Treble: press the left and right key to adjust SPDIF MODE Auto...
- Page 10 Blue Screen: press the left and right key to set blue screen On or off. Backlight: press the left and right key to adjust , which can be set to 0~10. Prevent Burn-in: press the left and right key to set prevent burn-in On or off. Reset: press OK key to reset OSD settings to default.
- Page 11 Through the left and right click on the icon, and then click on the "music" and the music open C disk. Selected music, press the OK key will appear the following icon. lcon 1: Play or Pause music. lcon 2: Fast backward the music play. lcon 3: Fast forward the music play.
-
Page 12: Mounting Guide
In order to prevent losing these screws, we suggest replacing the screws in their original holes. 2. Attach the VESA mounnt ((0E-32MON720P (200mm x 100mm)0E-43MON1080 (200mm x 200mm)) plate to rear of the monitor and follow all of the instructions provided with the mount to complete the mounting process. -
Page 13: Accessories
Accessories MUTE M EN U SOU RC E H D MI IR Remote Control AAA Batteries Power Cable HDMI Cable Qty: 2 Qty: 1 Qty: 1 Qty: 1 Screws for Installing Monitor Stand Screws for Mounting Monitor User Manuals Base of Stands Qty: 2 Screws Type: Screws Type: 32”/43”... -
Page 14: Dimensions
Dimensions Model 0E-32MON720P 0E-43MON1080 Letter Dimension inch inch Width of monitor body 28.8 972.5 38.2 Height of monitor body Depth of monitor body 45.9 47.1 1.85 Height of monitor on base 474.6 18.7 608.2 23.9 Width of base 684.2 26.9 913.5... -
Page 15: Specifications
Specifications Model 0E-32MON720P 0E-43MON1080 Screen Diagonal Dimension (inches) 32” 43” 27.4 x 15.4 37 x 20.8 Viewable Area W x H (inches) DLED Led Type Pixel Pitch (mm) 0.510 x 0.510 0.4902 x 0.4902 Display Resolutions 1366 x 768 1920 x 1080... -
Page 16: Limited Warranty
Limited Warranty 1. Limited Warranty A. General Subject to the terms and conditions of this Limited Warranty, from the date of sale through the period of time for product categories specified in Section 1(b), ADI warrants its W Box Technologies products to be free from defects in materials and workmanship under normal use and service, normal wear and tear excepted. - Page 17 B. Specific Warranties for Product Categories Product Categories Warranty CCTV Power Supplies 24 months Semi Commercial Monitors 24 months CCTV Monitors 30 months Video Baluns 30 months Analog Cameras 36 months DVR’s, NVR’s (excluding HDD) 60 months IP Cameras 60 months Racks 60 months TV Mounts...
- Page 18 Any product description (whether in writing or made orally by ADI or ADI’s agents), specifications, samples, models, bulletin, drawings, diagrams, engineering sheets, or similar materials used in connection with the Buyer's order are for the sole purpose of identifying ADI's products and shall not be construed as an express warranty or condition. Any suggestions by ADI or ADI's agents regarding use, applications or suitability of the products shall not be construed as an express warranty or condition unless confirmed to be such in writing by ADI.
- Page 19 4. Returns Subject to the terms and conditions listed below, during the applicable warranty period, ADI will replace Product or provide a credit at purchase at its sole option free of charge any defective products returned prepaid. Any obligations of ADI to replace Limited Lifetime warranty products pursuant to this warranty which result from defect are limited to the availability of replacement product.
- Page 20 0E-32MON720P Tech Support 4 0 0 4 9 3 0 1 2 4 0E-43MON1080 #833-574-9124(Option2) info@wboxtech.com wboxtech.com 4 0 0 4 9 3 0 3 4 0...
