- Page 1 ULTRA HD PRO-GRADE LED COLOR MONITOR Tech Support #833-574-9124(Option2) info@wboxtech.com 0E-28LED4K2...
-
Page 2: Table Of Contents
Contents Contents ............................1 Safety ............................1 Cautions............................3 FCC RF Interference Statement ..................4 Connections ..........................5 Controls & Menu Operation ....................6 Mounting Guide ........................ 12 Accessories ..........................13 Power Indicator / Modes of Operation ................13 Dimensions ..........................14 Specifications ........................ - Page 3 D. If batteries are used, please dispose of all batteries as per local regulations. E. Use the monitor in indoor environments as per the temperature and humidity specs. 8. The monitor should be operated from a power source indicated on the rear of the monitor. 9.
-
Page 4: Cautions
Cautions CAUTION TO SERVICE PERSONNEL POWER SUPPLY CORD IS USED AS MAIN POWER DISCONNECT DEVICE IN THIS PRODUCT. UNPLUG THIS PRODUCT FROM THE WALL OUTLET BEFORE REMOVING THE BACK COVER AND SERVICING. 1. Never open the monitor case Only specially qualified personnel should open the case. No user serviceable parts inside. 2. -
Page 5: Fcc Rf Interference Statement
FCC RF Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 6: Connections
Connections Back View of Monitor Connector panel is located on the underside of the case rear projection, just above the stand. Detailed View of the Connector Panel Only use a properly, grounded, three wire cord appropriate for the local power system. Remote control The remote control offers various shortcuts and added convenience... -
Page 7: Controls & Menu Operation
Control Keys / Buttons POWER Buttons are located on the right side of the 16:9/4:3 Bezel on 0E-28LED4K2 models. Source Auto detection function when there is/are source(s) connect to the monitor, monitor will auto detect the source(s) and auto select the desired source. The source should be selected manually when there is more than one source connected to the monitor. - Page 8 D. “RIGHT” button ●Press RIGHT button, volume increase E. “DOWN” button ●Press the button to scroll the cursor to desired function. ●Press the DOWN to decrease the value of selected function in sub OSD menu. F. “UP” button ●Press the button to scroll the cursor to desired function.
- Page 9 Picture Menu The “PICTURE” menu is for adjusting the image appearance and parameters. The Picture menu is the same for BNC/CVBS and HDMI; the Picture menu options differ for VGA. Picture Menu (BNC/CVBS & HDMI) Press the MENU button to bring the menu on Picture Mode Standard screen, and then the right/left buttons to move...
- Page 10 Adjustments Noise Reduction: Reduce noise of the display image (LOW/MIDDLE/HIGH/OFF) Color Temperature: Adjust color reproduction: Noise Reduction Middle Color Temperature Medium choose between Warm/User/Cool/Medium. In the “USER” setting, you have full Green control to alter the individual settings “Red:0-100, Blue Green: 0-100, and Blue:0-100.
- Page 11 Adjustments Auto Adjust: Fit the image setting automatically Horizontal Pos: Adjust the horizontal position of picture 0-100 Vertical Pos: Adjust the vertical position on screen Size: Adjust the display size 0-100 Phase: Reduce video distortion and instability components Audio Menu Press the MENU button to bring the menu on screen, and then left/right buttons to move Sound Mode...
- Page 12 OSD Menu Press the MENU button to bring the menu on screen, and then left/right buttons to move along the menu selections to highlight the OSD menu. Press up/down to move the left side main menu selector into the window of menu choices and parameters.
-
Page 13: Mounting Guide
In order to prevent losing these screws, we suggest replacing the screws in their original holes. 2. Attach the VESA mount ((0E-28LED4K2 (100mm x 100mm)) plate to the rear of the monitor and follow all of the instructions provided with the mount to complete the... -
Page 14: Accessories
Screws Type: HM 6.0×10mm Qty: 4 Screws Type: HM 6.0x10mm Qty: 4 Qty: 1 ULTRA HD PRO-GRADE LED COLOR MONITOR Tech Support #833-574-9124(Option2) info@wboxtech.com 0E-28LED4K2 Allen Wrench Batteries Base of Stands Stand Supports User Manuals Qty: 1 Qty: 2 Qty: 2... -
Page 15: Dimensions
Dimensions Model 0E-28LED4K2 Letter Dimension inch Width of monitor body 661.5 26.04 Height of monitor body 388.9 15.31 Depth of monitor body 52.7 2.07 Height of monitor on base 462.8 18.22 Width of base 16.1 Depth of base 159.8 6.29 Width of viewable area 623.9... -
Page 16: Specifications
Specifications Model 0E-28LED4K2 Screen diagonal dimension (inches) 25.55*14.54 Viewable area W x H (inches) Led Type Pixel pitch (mm) 0.16 x 0.16 Screen maximum Resolution 3840 x 2160 Up to 4K 60Hz.downward compatible Display Resolutions Up to 4K 60Hz. downward compatible Supported Input Resolutions Up to 60Hz@3840 x 2160.downward compatible... -
Page 17: Limited Warranty
Limited Warranty 1. Limited Warranty A. General Subject to the terms and conditions of this Limited Warranty, from the date of sale through the period of time for product categories specified in Section 1(b), ADI warrants its W Box Technologies products to be free from defects in materials and workmanship under normal use and service, normal wear and tear excepted. - Page 18 B. Specific Warranties for Product Categories Product Categories Warranty CCTV Power Supplies 24 months Monitors 30 months Video Baluns 30 months Analog Cameras 36 months DVRs, NVRs (excluding HDD) 60 months IP Cameras 60 months Racks 60 months TV Mounts 60 months Analog Cables Limited Lifetime...
- Page 19 Any product description (whether in writing or made orally by ADI or ADI’s agents), specifications, samples, models, bulletin, drawings, diagrams, engineering sheets, or similar materials used in connection with the Buyer's order are for the sole purpose of identifying ADI's products and shall not be construed as an express warranty or condition. Any suggestions by ADI or ADI's agents regarding use, applications or suitability of the products shall not be construed as an express warranty or condition unless confirmed to be such in writing by ADI.
- Page 20 4. Returns Subject to the terms and conditions listed below, during the applicable warranty period, ADI will replace Product or provide a credit at purchase at its sole option free of charge any defective products returned prepaid. Any obligations of ADI to replace Limited Lifetime warranty products pursuant to this warranty which result from defect are limited to the availability of replacement product.
- Page 21 0E-28LED4K2 Tech Support E505978 #833-574-9124(Option2) info@wboxtech.com LED MONITOR 1 1 9 1 4 0 2 9 7 9 wboxtech.com...
