General Notes
1. Unpack the cabinet. Check the box thoroughly
for all hardware and loose parts as follows:
A. Cabinet B. Hardware Bag
D. "Z' Bracket E. SOMM Magnifying Mirror
2. Remove the doors from the cabinet and store the
doors in the cabinet box. Be sure edges of the doors
are protected. Removing the doors allow for easy and
fast installation of the cabinet system.
3. A square and plumb installation insures proper door
operation. A square and level are necessary for
proper installation.
4. Improper installation voids the warranty. Installed
cabinets cannot be returned.
5. If you experience any problems with your Métallique
cabinet contact your dealer or Robern directly.
Robern • 701 N Wilson Ave • Bristol, PA 19007
800 877 2376 • FAX 215 826 9633
Limited Warranty One Year Term
ROBERN warrants to the original purchaser that, it will, at its elec-
tion repair, replace, or make appropriate adjustment to products
made by this company shown to have significant defects in mate-
rial or workmanship which are reported to ROBERN in writing
within one (1) year from the date of delivery. ROBERN is not
responsible for installation costs.
The warranty is void in the event the product is damaged in transit,
or if damage or failure is caused by abuse, misuse, abnormal
usage, faulty installation, damage in an accident, improper mainte-
nance, or any repairs other than those authorized by ROBERN.
At the expiration of the one year warranty period, ROBERN shall
be under no further obligation under any warranty, expressed or
implied, including the implied warranty of merchantability.
ROBERN shall not be liable for any consequential damages aris-
ing out of or in connection with the use or performance of its
products. Some states do not allow limitations on how long an
implied warranty lasts or do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
Any liability against ROBERN under any implied warranty, includ-
ing the warranty of merchantability, is expressly limited to the
terms of this warranty. Permission to return any merchandise
under this warranty must be authorized by ROBERN and returned
prepaid by the purchaser. Claims under this warranty should be
sent directly to your dealer.
MT System is patented.
PAT NO. 5,355,627
©2003 Robern
All rights reserved. REV.3
MÉTALLIQUE 30" HIGH CABINET
C. Shelving
3/03
Part List – Métallique Cabinet
1. MT20D4 Cabinet
or MT24D4 Cabinet
2. Glass Shelves
– 3 Shelves are provided
with each cabinet
3. "Z" Mounting Brackets
– Bracket used for surface
mounted cabinets.
4. Hardware Bag • Contains the Following
A. 12 Clear Snap-In Shelf Clips
B. 46 Shelf Hole Plugs
C. 6 SMS/WOOD Screws #10 X 2"
D. 5 SMS/Wood Screws #10 X 3"
E. 8 Connector Block Screws #10 X 1/2"
F. 2 MP65 Connector Blocks
G. 15 Grey Screw Head Caps
H. 3 Top Mount "Z' Clip
I. 6 Plastic Anchors
1. Dimensions of Cabinets
1. The MT-30 Series is a modular system allowing you
to install cabinets in different combinations. Overall
size of the cabinet is determined by the overall
dimensions of the assembled units.
Model No.
MT20D4MD
MT24D4MD
Robern
701 N. Wilson Ave.
Bristol, PA 19007
800.877.2376
Overall
19 1/4" X 30"
23 1/4" x 30"
