SMART SE240 Quick Reference

Quick Reference - SMART Hub SE240
Page Sorter
Whiteboard toolbar:
1 2 3 4
8 9
5 6 7
No. Description
1 Creates a new Whiteboard file.
2 Opens an existing file from a USB storage device.
3 Deletes a page.
4 Inserts a page.
5 Saves the Whiteboard file to a USB storage device.
Sidebar
(Expanded)
Installation and User's Guide
See document 122178 for more information on how to install and
use the SMART Hub SE240.
Click Computer One or Computer Two to expand the sidebar.
Sidebar
(Collapsed)
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
No. Description
6 Attaches the Whiteboard file to an e-mail message.
7 Goes to the previous page.
8 Goes to the next page.
9 Scrolls back four pages.
10 Scrolls forward four pages.
No. Description
11 Switches to Whiteboard mode.
12 Switches to computer one.
13 Switches to computer two.
14 Switches to S-Video.
15 Switches to composite video.
16 Views a presenter's shared screen in SMART Bridgit™.
17 Resets the room and starts a new session.
18 Switches to cursor.
19 Writes in digital ink, and chooses line style.
20 Erases digital ink.
21 Captures and places images in a Whiteboard file.
22 Freezes the video on your display.
23 Opens SMART Keyboard.
24 Sets the next press to a right-click.
25 Clears the digital ink from your display.
26 Moves the sidebar right or left.
27 Collapses and expands the sidebar.
28 Adjusts the volume.
29 Accesses the SMART Hub SE240's Help, Orient and
System Settings.
Firmware
To get the most out of your SMART Hub SE240, upgrade your
firmware to Version 3.0.X. Also upgrade your firmware if your
sidebar doesn't appear like the one to the left.
System Help
The SMART Hub SE240 includes System Help. To view
the System Help, press System on the sidebar, and then press
Help.
Visit the SMART Support website
SMART Hub SE240, or for access to the user and installation
guides.
10
for more information on the
99-00860-21 A0
