BRIO 97HSA Quick Start Manual

Required Hardware
Available kits:
97HSA-_20
97HSA-_30
97HSA-_40
97HSA-_60
*94P Polypropylene Channel
2, 3, 4, and 6m lengths supplied
97SR Rebate for 44.5[1.75] Panels
not supplied in kits
available in 2, 3, 4, and 6m
Preparing Wood Saddle and Rebate
97HSA Preparation
W
JT
FIXED REBATE
Cut 97HS57 & 94P to length = W+2(JT)-6[0.24]
Cut 97SR to length = W
W = Opening width between jambs
JT = Jamb Thickness
System Details
121.6[4.79]
JW = Jamb Width
PT = Panel Thickness either 44.5[1.75] or 57.2[2.25]
For 57.2[2.25] panels do not use 97SR and use rebate T
97HSA Self Draining Sill
Brio Australia
P: +61 2 87186718
W: brio.com.au
E: sales@brio.com.au
anodizing color not specified, items included in kits denoted with *
*97HS57 Aluminum Extrusion
2, 3, 4 and 6m lengths supplied
*97EC End Caps
1 set supplied per kit
Notch 97HS57
each end
N = JT-3[0.12]
3[0.12]
JW
6[0.24]
PT
Brio UK
P: +44 191 2291224
W: briouk.com
E: sales@briouk.com
Assembled Sill
dimensions in mm[inches]
Cutting Wood Saddle
N
XT and XT decided by installer
1
7.5
[0.30]
FIXED REBATE
Cut to length = W
T
1A
52.7[2.08]
T
2
31.8[1.25]
3.9[0.15]
Cut to length = W+2(JT)-6[0.24]
Seal AQ21 can be purchased
from Brio for the full perimeter seal
1B
INST97HSA1 REV C - MAY 2015
Brio USA
P: +1 585 3195599
W:
E: sales@briousa.com
2
13.4
[0.53]
19.1[0.75]
6.4[0.25]
11.9[0.47]
25.4
[1.00]
11.9[0.47]
briousa.com
wood not
supplied
20.9
T
1A
[0.83]
XT
1
T
1B
XT
2
31.8
T
2
[1.25]
1
