BRIO WT50 -18/3 series Installation Instructions Manuallines

Brio

Pack components

PACKS
WT50-18/3* x1(1800)
WT50-21/3* x1(2100)
WT50-24/3* x1(2400)
WT50-27/3* x1(2700)
WT50S-18/3* x1(1800)
WT50S-21/3* x1(2100)
WT50S-24/3* x1(2400)
WT50S-27/3* x1(2700)
*Aluminium finishes: PWT = white powdercoat, CA = clear anodised

Head and Sill Preparation

Screw fixings to be staggered along length, avoiding 257mm from ends of head guide if using soft close
21
257
X 400
X = 20
PRE-DRILL AND
FIX PAN HEAD
SCREWS THROUGH
VEE GROOVE
X 400
Wardrobe Roll Trio 50kg
®
Allegion (New Zealand) Limited
P: +64 9 829 0550
W: brionz.com
E:
nzinfo@allegion.com
No. 58
HEAD GUIDE
No. 57
SILL
55 53 56
x1(1800) x1(1800)
x1(2100) x1(2100)
x1(2400) x1(2400)
x1(2700) x1(2700)
x1(1800) x1(1800)
x1(2100) x1(2100)
x1(2400) x1(2400)
x1(2700) x1(2400)
FINISHED OPENING
WIDTH (W)
No. 50WR-S
SOFT CLOSE
LINTEL
400 400
No. 58
HEAD GUIDE
400 400
No. 56 No. 53C
SILL COVER SILL COVER
CLIP
No. 50WR No. 50G
ROLLER GUIDE
53C SP6X16Z
x6 x30
x7 x33
x8 x36
x9 x41
x6 x42
x7 x45
x8 x48
x9 x50
head, sill and sill cover cut to length 'W' (finished opening width )
20 MIN.
25 MAX.
35
X
THICKNESS
3 MIN.
No. 57
8 MAX.
SILL WITH
No. 56
9
SILL
COVER
X
No. 53C
SILL COVER CLIP
INSTBRIOWT502 REV C - AUG 2018
50SCT:
SP6X16Z
PAN HEAD
SCREWS
OPTIONAL SOFT CLOSE KIT
50G 50WR
x6 x6
x6
x6
x6 x6
x6
x6
x6 x6
x6
x6
x6 x6
x6
x6
134.4
PANEL
30 MIN.
40 MAX.
No. 56
SILL COVER
134.4
No. 50WR-S
SOFT CLOSE
No. 50WR-C
SOFT CLOSE
CATCH
50WR-S 50WR-C
x6 x6
x6 x6
x6 x6
x6 x6
No. 58
HEAD
GUIDE
PANEL
HEIGHT
(PH)
No. 57
SILL
1
