5. TECHNICAL CHARATERISTICS.

Cathode-ray tubes
Tuning-system
Reception system
Colour system
Program selection
Audio
Speakers
Aerial
Jack for headphones
Clock and alarm Function
Timer Function
AV connectors
Power supply
Consumption
Radio
Hotel mode
Options by means of Technical Service:
NTSC-M

6. Safety

It fulfils the safety requirements established in the regulation:
• EN 60065:93

7. EMC (Electromagnetic Compatibility)

It fulfils the EMC requirements established in the regulation:
• EN 55013:1990/A12:1994
• EN 55020:1994
• EN 60555-2:1987
In-Line, Hi-bipotential gun. 14" (34 cm)
Voltage synthesis, 100 programs in non-volatile memory, AFT, Fine-tuning (10 first
programs), automatic, semiautomatic and manual channel-search.
Band I, channels 2-4 (VHF)=E2-E4
Cable channels S1-S20
Hyperband channels S21-S41
Band III, channels 5-12 (VHF)=E5-E12
Band IV-V, channels 21-69 (UHF)=E21-E69
B/G Model CE14A2-C
B/G-D/K Model CE14A2-E
B/G-L-L' Model CE14AS2-F
PAL, NTSC 4.43, N.A.P. (NTSC Amusement by PAL)Models
PAL/SECAM ntsc 4,43, N.A.P. Model CE14AS2-F
Sequential selection from the controls on the set. Direct selection to any program
from the remote-control device.
Power-rating 1W rms. (10% distortion)
Ω
1 of 8 .
External aerial sockets 75 Ω IEC
Mono jack 3,5mm.
Switch on and off of CTV programmable in real time.
1 Scart connector 21 pin CENELEC standard AV, RGB and S_Video.
1 RCA Video input (frontal)
1 RCA Audio input (frontal)
220 – 240 VAC 50Hz
47W (maximum consumption).
29W (IEC 107-1)
3,1 W (Stand-by )
87.5 – 108MHz. 40 memories. Manual and semiautomatic search
Hotel mode and Hotel Rental
