INSTRUCTION MANUAL
Colour Television
Specification
Common specification
Power source
AC 110~120V, 220~240V 50Hz
Television system
System I
Colour system
PAL (PAL/NTSC3.58 in AV mode)
Channel coverage
UHF: 21-69,
Aerial input impedance
75 ohm
AV terminal
AV1: CENELEC Standard
Input: Composite video, RGB and audio-L/R
Output: TV-output with composite video and audio-L/R
AV2: CENELEC Standard
Input: Composite video, RGB, S-VHS and audio-L/R
Output: Monitor-output with composite video and
audio-L/R
Please read this Instruction book before using your television.
We wish you many hours of pleasure from your new television.
17LC4-B
CE
17LC4BK-B
CE
17LC4W-B
CE
23LC4-B
CE
23LC4BK-B
CE
23LC4W-B
CE
Side AV terminal
AV3: RCA jacks
Input: Composite video and audio-L/R
Headphone socket Mini Jack
CE17LC4-B
CE17LC4BK-B
CE17LC4W-B
Sound output
(Continuous)
2 x 2W
Contrast Ratio
600:1
Screen(inches)
17
(viewing measured diagonally)
Display Resolution
1280 x 768 (WXGA) 1280 X 720 (WXGA)
Viewing angles
H:176°, V:176°
Dimensions (WxHxDmm) 452 x 409 x 237
(including stand)
Weight (kg)
6.5
CE23LC4-B
CE23LC4BK-B
CE23LC4W-B
2 x 5W
800:1
23
H:176°, V:176°
580 x 480 x 257
8.4
