Autoplugin RCP-V5 User Manual page 6

is other than specified
in 6.3,6.4
6.7. Flashing
frequency for 6.3-6.4
Setup items
7.3. Notification
7.
Output signals on the output
signals "Alert_1"
adjustment
7.4. Notification
signals on the output
"Alert_2"
7.5. Signal feed to the
output "Status Minus"
7.6. Signal feed to
the output
"Status_Plus"
8.1. Default Settings
8.
Service
menu
* Factory setting
Recommended settings marked in italics
1
–RCP turns off the heater if the battery voltage lowers below preset
2
– Signals appear only during heater autonomous operation
3
– Signal is used for indication by the hazard flashers. It uses 1-wire connection to
the hazard alarm button (see installation manual for details)
4
– Additional connections are required (see installation manual)
6
6.7.1 One flash within 3 sec
6.7.2 One flash within 5 sec
6.7.3 * One flash within 10 sec
6.7.4 One flash within 15 sec
7.3.1 *"Heater started"
7.3.2 "Heater stopped"
2
7.3.5 "Heater started to burn"
7.3.7 "Error occurred"
7.3.8 Disable the output
7.4.1 "Heater started"
7.4.2 *"Heater stopped"
7.4.5 "Heater started to burn"
7.4.7 "Error occurred"
7.4.8 Disable the output
7.5.1 Heater operates (potential)
7.5.2 *Heater operates autonomously
(from battery, engine is off) (potential)
7.5.3 Flashers control signal (double
impulses with the frequency adjusted by
6.7, applying settings 6.3-6.5)
7.5.4 Engine runs (potential)
7.5.5 Engine runs (RPM impulses)
7.5.6. Disable the output
7.6.1 Heater operates (potential)
7.6.2 Heater operates autonomously (from
battery, engine is off) (potential)
7.6.3 Engine runs (potential)
7.6.4 Ignition is on (potential)
7.6.5. Disable the output
8.1.1 Apply factory settings
3
