Reference Manual
Industrial 8-port unmanaged Gigabit PoE Ethernet Switching HUB
SH-9008AT-POE
CONTENTS
Introduction .................................................................. 4
Safety Precautions ...................................................... 9
Product Nomenclature and Function ............... 16
Setting Up ................................................................... 24
Appendix ...................................................................... 30
Customer Support and Inquiry ............................ 35
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Contec SH-9008AT-POE
Summary of Contents for Contec SH-9008AT-POE
- Page 1 Reference Manual Industrial 8-port unmanaged Gigabit PoE Ethernet Switching HUB SH-9008AT-POE CONTENTS Introduction ..............4 Safety Precautions ............9 Product Nomenclature and Function ....16 Setting Up ..............24 Appendix ..............30 Customer Support and Inquiry ......35...
-
Page 2: Table Of Contents
Table of Contents Introduction ..............4 1. Related Manuals ..............................5 2. About the Product ..............................6 3. Features ..................................7 4. Product Configuration List ..........................8 Safety Precautions ............9 1. Safety Information ............................... 10 2. Handling Precautions ............................11 1. FCC PART 15 Class A Notice ........................13 2. - Page 3 Table of Contents Customer Support and Inquiry ........35 1. Services ..................................36 - 3 -...
-
Page 4: Introduction
Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. - 4 -... -
Page 5: Related Manuals
— — Introduction SH-9008AT-POE Reference Manual 1. Related Manuals The manuals related to the product are listed below. Read them as necessary along with this document. Must Read the Following Manuals. Name Purpose Contents How to get Product Guide... -
Page 6: About The Product
— — Introduction SH-9008AT-POE Reference Manual 2. About the Product This product is an 8-port industrial switching HUB which conforms to IEEE802.3ab (1000BASE-T) /IEEE802.3u (100BASE-TX) /IEEE802.3 (10BASE-T) standard, and it is capable of PoE power supply based on IEEE802.3af, IEEE802.3at. -
Page 7: Features
— — Introduction SH-9008AT-POE Reference Manual 3. Features PoE power supply function based on IEEE802.3af, IEEE802.3at Power can be supplied to PoE devices that conform to IEEE802.3af, IEEE802.3at. Up to 30W per port and up to 120W * for all ports can be powered. -
Page 8: Product Configuration List
— — Introduction SH-9008AT-POE Reference Manual 4. Product Configuration List The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product…1 Product Guide...1 Warranty Certificate...1... -
Page 9: Safety Precautions
Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. - 9 -... -
Page 10: Safety Information
— — Safety Precautions SH-9008AT-POE Reference Manual 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely. -
Page 11: Handling Precautions
— — Safety Precautions SH-9008AT-POE Reference Manual 2. Handling Precautions WARNING Always check that the power is turned off before connecting or disconnecting power cables. Do not modify the product. Do not use the product in locations exposed to a flammable or corrosive gas. It may cause ... - Page 12 When removing connectors or cables, always unplug the power cables connected to the product first. Do not modify the product. CONTEC will bear no responsibility for any problems, etc., resulting from modifying the product. In the event of failure or abnormality (foul smells or excessive heat generation), un-plug the ...
-
Page 13: Fcc Part 15 Class A Notice
— — Safety Precautions SH-9008AT-POE Reference Manual 1. FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 14: Usage Limitation
— — Safety Precautions SH-9008AT-POE Reference Manual 3. Usage limitation This product has not been developed or manufactured to be used in systems including the equipment which is directly related to human lives *1 or the equipment which involves human safety and may significantly affect the maintenance of public functions *2. -
Page 15: Environment
— — Safety Precautions SH-9008AT-POE Reference Manual 4. Environment Use this product in the following environment. If used in an unauthorized environment, the board may overheat, malfunction, or cause a failure. Operating temperature -35 - +50ºC Humidity 5 - 95%RH (No condensation) -
Page 16: Product Nomenclature And Function
Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. - 16 -... -
Page 17: Nomenclature Of Product Components
— — Product Nomenclature and Function SH-9008AT-POE Reference Manual 1. Nomenclature of Product Components Component names of the product are shown in the figure below. Name Name Power LED Bracket Screw Holes for DIN-rail Installation Power Failure Detection Relay LED... -
Page 18: Description Of Product Components
— — Product Nomenclature and Function SH-9008AT-POE Reference Manual 2. Description of Product Components Components such as connectors, switches are described. 1. LAN Port This product has 8 LAN ports. Pin Assignment Pin number Description BI_DA+ with PoE power Output +... -
Page 19: Power Supply Connector
— — Product Nomenclature and Function SH-9008AT-POE Reference Manual 2. Power Supply Connector Use the 6-pin connector to connect to external power. Pin Assignment Pin number Signal name Description PWR-1 power supply (12 - 57VDC±5%) PWR-1 power supply (GND) FCOM... -
Page 20: Power Failure Detection Dip Switch
— — Product Nomenclature and Function SH-9008AT-POE Reference Manual 3. Power Failure Detection DIP Switch Power output failure can be detected with the set of the DIP switch. The relay pins (pin-3 and pin-4) of the power connector are open in normal operation mode, but they are closed before the power is supplied or when the power output of the PWR-1 or PWR-2 drops. -
Page 21: Led Indicator
— — Product Nomenclature and Function SH-9008AT-POE Reference Manual 4. LED Indicator Status of the product is indicated by ON/OFF and flashing of LED. Color and Description Color Display Description Green Power of PWR1 has been supplied. Power of PWR1 has not been supplied. -
Page 22: Connecting To Network
— — Product Nomenclature and Function SH-9008AT-POE Reference Manual 3. Connecting to Network 1. Network Cable Use the cable suitable for the following specifications. Supply the power to the connected devices by PoE function 100BASE-TX, 10BASE-T: Category 5 or greater, UTP/STP cable within 100 meters ... -
Page 23: Connection Restrictions
— — Product Nomenclature and Function SH-9008AT-POE Reference Manual 2. Connection Restrictions Connection Restrictions with 100BASE-TX Repeater HUBs At Class I, cascade connection with 100BASE-TX repeater HUBs is impossible. Up to two stages of cascade connection between 100BASE-TX Class II repeaters is possible. In addition, the total maximum cable length of cables (1)(2)(3) is 205m or less. -
Page 24: Setting Up
Setting Up This section describes how to set up the product. - 24 -... -
Page 25: Power Supplies
— — Setting Up SH-9008AT-POE Reference Manual 1. Power Supplies Power can be supplied with the power supply connector. Select the power cable listed below or its equivalent. Function Power connector : mfd. by Dinkle 2EHDVC-06P (5.08mm pitch) Compatible cable : AWG28-16 (The cable length should meet the power specification required.) The hub can be operated by supplying the power to either PWR-1 or PWR-2. -
Page 26: Installation
— — Setting Up SH-9008AT-POE Reference Manual 2. Installation 1. Mounting on a DIN rail Secure the DIN-rail mounting bracket on the product with flat-head (M3) screws. The appropriate tightening torque for the screw is less than 5kgf٠cm. *The bracket is preset on the product upon shipment. -
Page 27: Removing From A Din Rail
— — Setting Up SH-9008AT-POE Reference Manual 2. Removing from a DIN Rail While pressing the product downward, lift it up from the lower part of the DIN rail. - 27 -... -
Page 28: Setting On The Wall
— — Setting Up SH-9008AT-POE Reference Manual 3. Setting on the Wall Secure the wall brackets on the product with round screws (M3). The appropriate tightening torque for the screw is less than 5kgf٠cm. Set the wall brackets on the wall with screws. Use the M3-size screws. -
Page 29: Spacing Between The System Unit And Any Surrounding Objects
— — Setting Up SH-9008AT-POE Reference Manual 4. Spacing between the system unit and any surrounding objects DIN rail mounted Secure a distance of at least 50mm between the top/bottom of the main product and any surrounding objects and also a distance of at least 50mm between each side of the product and any surrounding objects (5.8mm for the product overview level side). -
Page 30: Appendix
Appendix This section lists the specifications and the physical dimensions of the product, and the details of model name. - 30 -... -
Page 31: Hardware Specifications
— — Appendix SH-9008AT-POE Reference Manual 1. Hardware Specifications Function Specifications Item Specifications Ethernet standards IEEE802.3/IEEE802.3u/IEEE802.3ab/IEEE802.3af/ IEEE802.3at*1 –compliant Data transfer rate 10Mbps/100Mbps/1000Mbps (auto-negotiation) Communications method All ports: Full/Half duplex (auto-negotiation) Flow control Full Duplex : IEEE802.3x compliant flow control Half Duplex : Back pressure... - Page 32 — — Appendix SH-9008AT-POE Reference Manual Installation Environment Requirements Item Description Operating ambient temperature -35 - +70°C Operating ambient humidity 5 - 95%RH (No condensation) Non-operating ambient temperature -38 - +70°C Non-operating ambient humidity 5 - 95%RH (No condensation) Floating dust particles...
-
Page 33: Physical Dimensions
— — Appendix SH-9008AT-POE Reference Manual 2. Physical Dimensions When the product is mounted on DIN rail - 33 -... - Page 34 — — Appendix SH-9008AT-POE Reference Manual When the product is set on the wall - 34 -...
- Page 35 Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. - 35 -...
- Page 36 — — Customer Support and Inquiry SH-9008AT-POE Reference Manual 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the CONTEC website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages. Membership registration (myCONTEC) is required to use the services.
- Page 37 No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.
- Page 38 CONTEC CO., LTD. 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. SH-9008AT-POE Reference Manual NA07245 (LYXZ541) [06222020]...
