- Page 1 F&eIT Series 10/100/1000M AUTO-MDIX Industrial switchingHUB For DIN rail, 8 ports SH-9008H-FIT User’s Manual CONTEC CO., LTD.
-
Page 2: Check Your Package
Setup Guide Acceptable connector Connector omission prevention metal fittings Flat putting fixing bracket Fixed screw M3×6 Rubber foot * The manual of this product can be downloaded from CONTEC homepage (http://www.contec.com/) free of charge. Rubber Acceptable Fixed foot screw connector... -
Page 3: Copyright
All relevant issues have been considered in the preparation of this document. Should you notice an omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD. Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may appear in this document or for results obtained by the user as a result of using this product. -
Page 4: Table Of Contents
Installation Conditions ........................14 Installation orientation ....................... 14 Spacing between the system unit and any surrounding objects ..........17 Nomenclature of unit Components and Their Settings Name of unit Components and Function ..................19 Connecting to a Network Network Cables..........................21 SH-9008H-FIT... - Page 5 Connecting a Personal Computer, another HUB unit or bridge ............21 Connection Restrictions with 100BASE-TX Repeater HUBs ..........22 Connection Restrictions with 10BASE-T Repeater HUBs ............22 System Reference Specification ............................. 23 Physical Dimensions ......................... 25 Differences from SH-9008-FIT ......................26 SH-9008H-FIT...
-
Page 6: Before Using The Product
1. Before Using the Product This chapter provides information you should know before using the product. About the Unit SH-9008H-FIT is a compact-sized [39(W) × 120(D) × 94(H) mm] industrial switching HUB unit that is compliant with the IEEE802.3ab (1000BASE-T)/IEEE802.3u (100BASE-TX)/IEEE802.3 (10BASE-T) standards. -
Page 7: Customer Support
You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC F&eIT products are warranted by CONTEC CO., LTD. -
Page 8: Safety Precautions
Do not use this product in extremely humid or dusty locations. It is extremely dangerous to use this product with its interior penetrated by water or any other fluid or conductive dust. If this product must be used in such an environment, install it on a dust-proof control panel, for example. SH-9008H-FIT... - Page 9 Do not open the unit casing. CONTEC will disclaim any responsibility for equipment whose casing has been opened. Do not modify the unit. CONTEC will bear no responsibility for any problems, etc., resulting from modifying this unit. To clean this product, gently wipe it with a soft cloth soaked with water or a neutral detergent. Do not use benzene, a thinner, or other volatile solvents as they can cause the coating to discolor or peel off.
-
Page 10: Environment
(3) Store the package at room temperature at a place free from direct sunlight, moisture, shock, vibration, magnetism, and static electricity. Disposal When disposing of the product, follow the disposal procedures stipulated under the relevant laws and municipal ordinances. SH-9008H-FIT... - Page 11 1. Before Using the Product SH-9008H-FIT...
-
Page 12: Setup Of Hardware
Figure 2.1. Mounting on a DIN rail < 1 / 2 > (2) The Latch metal fittings is automatically locked, and the unit can be mounted in one-touch. Figure 2.2. Mounting on a DIN rail < 2 / 2 > SH-9008H-FIT... -
Page 13: Removed Din Rail
Figure 2.3. Removing the unit from the DIN rail with phillips-head screw driver < 1 / 3 > (2) The latch metal fitting is pushed down and the product can be removed from the DIN rail. Figure 2.4. Removing the unit from the DIN rail with phillips-head screw driver < 2 / 3 > SH-9008H-FIT... - Page 14 Figure 2.6. Removing the unit from the DIN rail with flathead screw driver < 1 / 3 > (2) The latch metal fitting is pushed down and the product can be removed from the DIN rail. Figure 2.7. Removing the unit from the DIN rail with flathead screw driver < 2 / 3 > SH-9008H-FIT...
- Page 15 2. Setup of Hardware (3) By lifting the unit, you can easily remove it from the DIN rail. Figure 2.8. Removing the unit from the DIN rail with flathead screw driver < 3 / 3 > SH-9008H-FIT...
-
Page 16: Mounting Of Flat Putting Fixing Bracket And Rubber Foot
DIN rail mounting brackets from the unit. This operation is performed for both flat putting fixing brackets and rubber feet. Figure 2.9. Removed of DIN rail fixing bracket Flat putting fixing bracket Fixes the unit with screws supplied with this product. Figure 2.10. Mounting of flat putting fixing bracket SH-9008H-FIT... - Page 17 2. Setup of Hardware Rubber foot Align with the four corners on the unit overview level side, and mount the rubber feet supplied with this product. Figure 2.11. Mounting of rubber foot SH-9008H-FIT...
-
Page 18: Mount Of Connector Omission Prevention Metal Fittings
2. Setup of Hardware Mount of connector omission prevention metal fittings Mounting (1) Connect an appropriate connector to the power connector, mount the connector detaching prevention metal fitting. Figure 2.12. Mount of connector omission prevention metal fittings SH-9008H-FIT... -
Page 19: Installation Conditions
Avoid installation on unsuitable installation directions as insufficient heat dissipation may occur. (Top) POWER 12-24VDC Suitable installation directions (Bottom) (Top) (Bottom) Unsuitable (Top) installation Ceiling directions Floor (Bottom) Figure 2.13. Installation direction (when the DIN rail fixing brackets mounted) SH-9008H-FIT... - Page 20 (Top) POWER 12-24VDC Suitable installation directions (Bottom) (Top) Ceiling Floor (Bottom) Figure 2.14. Installation direction (when flat putting fixing brackets mounted) SH-9008H-FIT...
- Page 21 Mount the rubber feet to install it if fixing brackets are not mounted in the case of horizontal installation. Avoid installation on unsuitable installation directions as this may cause insufficient heat dissipation and overturning. (Top) Suitable installation directions Floor (Bottom) (Top) POWER 12-24VDC SH-9008H-FIT Floor Floor Floor (Bottom) Unsuitable (Top) installation directions Floor Floor (Bottom) Figure 2.15.
-
Page 22: Spacing Between The System Unit And Any Surrounding Objects
50mm between each side of the unit and any surrounding objects (5.8mm for the unit overview level side). 100 or more or more POWER 12-24VDC 50 or more [mm] Figure 2.16. Spacing between the system unit and any surrounding objects while the DIN rail mounted SH-9008H-FIT... - Page 23 50mm between each side of the unit and any surrounding objects. 50 or more 50 or more 50 or more 50 or more [mm] Figure 2.17. Spacing between the system unit and any surrounding objects while flat putting fixing brackets and rubber feet mounted SH-9008H-FIT...
-
Page 24: Nomenclature Of Unit Components And Their Settings
You can prevent connectors from being omitted by connector omission prevention metal fittings. You can connect cables by screw cramps. Power Supply Connector MC1,5/3-G-3,5 (PHOENIX CONTACT) 12 - 24VDC Pin Number Signal Description Power (12-24VDC±5%) Power(GND) Frame Ground SH-9008H-FIT... - Page 25 For power supply, use the power supply that rises within an input voltage range of 11.6VDC or higher within 50msec. The power supply that cannot meet this requirement may cause device failure or accident. Input voltage (V) 25.2 11.6 Time (ms) Figure 3.2. Graph of Rise Time of Power Supply SH-9008H-FIT...
-
Page 26: Connecting To A Network
When using Jumbo Frame, it is necessary for other network devices of the communication partner, such as LAN adapters, to be Jumbo Frame compatible. CPU-CA20(FIT)GY, SH-9008H-FIT CPU-CA10(FIT)GY .,etc Straight or cross cables Figure 4.1. An example for connection with PC or other HUBs and control modules... -
Page 27: Connection Restrictions With 100Base-Tx Repeater Hubs
100BASE-TX Class II repeaters is possible. In addition, the total maximum cable length of cables (1)(2)(3) is 205m or less. For details, see the operation manual of your100BASE-TX repeater HUB. SH-9008H-FIT 100BASE-TX HUB(Class II) 100BASE-TX HUB(Class II) - Use UTP and STP cables with category 5 or higher for cables (1)(2)(3). -
Page 28: System Reference
Fixation with the mounting phase by using the flat putting fixing bracket and rubber feet. When using Jumbo Frame, it is necessary for other network devices on the communication route to be Jumbo Frame compatible. SH-9008H-FIT... - Page 29 Vibration 40minutes each in X, Y, and Z directions Sweep resistance resistance (JIS C60068-2-6-compliant, IEC60068-2-6-compliant) Impact resistance 15G, half-sine shock for 11ms in X, Y, and Z directions (JIS C60068-2-27-compliant, IEC60068-2-27-compliant) Grounding Class D grounding (previous class 3 grounding) SH-9008H-FIT...
-
Page 30: Physical Dimensions
5. System Reference Physical Dimensions 12-24VDC [mm] Figure 5.1. Physical dimensions when Din rail fixation metal fittings (standard) are installed 4-φ4 [mm] Figure 5.2. Physical dimensions when flat putting fixing brackets is installed SH-9008H-FIT... -
Page 31: Differences From Sh-9008-Fit
5. System Reference Differences from SH-9008-FIT SH-9008H-FIT, the higher-grade model of the conventional SH-9008-FIT, has the main differences as follows: SH-9008-FIT SH-9008H-FIT Capacity of buffer 176Kbyte 512Kbyte Power consumption (Max.) For 12V input : 0.6A, For 12V input : 0.65A, For 24V input : 0.4A... - Page 33 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [05252016] Management No. NA05016 Parts No. LYTZ191...
