1. General Description

The information contained in this document is proprietary to TCL SZ FPD lab and shall
not be disclosed by the recipient to third persons without the written permission of the
team leader or GM of R&D.
RT95-AP chassis are designed for Asia & Pacific (AP) market Ready for Smart TV. It
features by its high integration, easy debugging (ADC adjustment free) as well as
convenience in terms of maintenance. Fast software upgrade through USB disk
facilitates both manufacture and after-sale service. Meantime, a variety of functions
involved in Factory Main Menu can not only bring benefits for production, but also
satisfy various demands of customers.
Note: Factory Main Menu (FMM) is divided into Factory menu, Design menu. Factory Menu
covers all indispensable functions during manufacture such as White Balance Adjustment,
USB Upgrading etc., while Design Menu includes Service Menu, Shop Menu, Hotel Menu,
Param Setting, Other Setting etc. Shop Setting(menu) contains many choices for default
settings after manufacture. Some settings like Param Setting and Other Setting is
exclusively used by R&D engineer, anyone else shouldn't change the settings in the menu.
When you wish to learn the product information like project ID, project name, chassis name,
software version, release date, you can access to Service Menu. In addition, in Hotel Menu,
we also provide a great deal of useful functions for specific applications in hotel.
The main chip is from RealTek and supports below features matrix:
Class
RF Input
(PAL/DVB/DVB-T2)
HDMI
(480i/p, 576i/p, 720p up to 1080i/p, with
HDCP)
VGA
Inputs
&
VGA audio
Outputs
Composite Video Input(HDTV)
Component Audio Input
AV Input
Factory Test & Alignment Specification For RT95-AP Series (V1.0)
Item
CABLE&ANTENNA
Shares audio sockets with YPbPr (L+R )
Shares Video(Pr) and audio sockets with YPbPr
3
RT95
2*HDMI
1
YPbPr(RCA*3)
L+R(RCA*2)
