- Page 1 U S E R ’ S G U I D E 76X6/94Z2 SERIES 220-240v Safety Instructions Product view Assembly Operations 10-15 Maintenance and Care 16-17 Troubleshooting Consumer Services Additional Accessories Replacement Parts Warranty ™...
- Page 2 BISSELL Multi Cyclonic vacuum We’re glad you purchased a BISSELL vacuum. Everything we know about floor care went into the design and construction of this complete, high-tech home cleaning system. By purchasing this product you are helping BISSELL with our commitment to reducing our impact on the environment through an expanding range of sustainable design efforts.
-
Page 3: Important Safety Instructions
Bs 1362) fuse is fitted in the carrier contained in the plug. (spares may be obtained from your BIssell supplier). If for any reason the plug is cut off, it must be disposed of, as it is an electric shock... -
Page 4: Product View
roduct view Handle TurboBrush ™ (TurboBrush ™ on select models) Power Switch Quick Release Cord Wrap Dirt Container Pre-Motor Filter Headlight Height Adjustment Knob Furniture Protection Guard CAUTIOn: Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures. -
Page 5: How To Use This Guide
Locate and organize all parts before assembly. following this user’s guide will greatly enhance your ability to get the most performance from your BISSELL vacuum for many years. ssembly The only tool you’ll need to assemble your vacuum cleaner is a Philips head screwdriver. -
Page 6: Operation
“Off” (O) for bare floor cleaning or other delicate surfaces. note: your BISSELL Lift-Off Multi Cyclonic vacuum is equipped with a special internal switch that turns the rotating brush off whenever the unit is in the Upright position. -
Page 7: Special Tools
Vacuum Hose. CAUTIOn: Always place vacuum cleaner on floor in its fully Upright Position and make sure it is locked into place before removing Canister or when using tools. Placing the... - Page 8 To reduce the risk of the shoulder strap coming loose in operation follow these instructions. CAUTIOn: Do not press the Release Button while using the Carrying Handle to transport the vacuum cleaner. The Canister could detach causing the rest of the vacuum to fall. Buckle...
-
Page 9: Power Cord Storage
Cleaning with the detachable canister The detachable canister feature makes it possible to easily take the powerful cleaning action of your BISSELL Lift-Off Multi Cyclonic to stairways, auto interiors, and other hard-to-reach areas of your home. Before detaching the canister, your vacuum must be in its fully upright position. -
Page 10: Maintenance And Care
aintenance and care To maintain maximum cleaning performance, the following maintenance steps must be performed: Empty the dirt container when the dirt reaches the “Full” line on the front. Check the pre-motor filter at least once a month and clean and replace as needed. Replace the HEPA media post-motor filter every six months. - Page 11 aintenance and care Cleaning the secondary cyclone Unplug the cleaner from electrical outlet. The secondary cyclone can be reached by removing the dirt container, reaching underneath the upper tank and turning the rim of the frame to unlock. Pull straight down to remove. The cyclone and screen may be separated for cleaning.
- Page 12 Unplug cleaner from electrical outlet. Remove detachable canister from vacuum cleaner Recline handle and turn vacuum cleaner over so bottom side is up. Remove the six screws as shown with a Phillips head screwdriver.
- Page 13 aintenance and care Replace light bulb Unplug cleaner from electrical outlet. Remove detachable canister and recline handle of vacuum. Using a screwdriver, remove the one screw as shown and lift off the lens. Remove the bulb from the socket by grasping bulb and pulling straight out.
- Page 14 Cleaning clogs Low suction or poor pickup may be due to a clog in the vacuum cleaner. If you notice a change in the sound of the motor or a reduction in the spinning action, check for clogs.
-
Page 15: Thermal Protector
If the thermal protector continues to activate after following the above steps, your cleaner may need servicing. Call BISSELL Consumer Services, or visit the website. note: The thermal protector controls the main vacuum motor only, not the brush motor. -
Page 16: Troubleshooting
Possible causes 1. Canister is not securely seated 2. Brush switch turned to "OFF" 3. Vacuum is in upright position vacuum cleaner won't pick up dirt Possible causes 1. Incorrect height adjustment 2. Hose not attached to suction opening 3. Crack or hole in hose 4. -
Page 17: Please Do Not Return This Product To The Store
3. Dirt container installed incorrectly Other maintenance or service not included in the manual should be performed by an Thank you for selecting a BISSELL product. Please do not return this product to the store. w w w . b i s s e l l . c o m Remedies 1. - Page 18 In the UK, Australia, New Zealand, the middle east or Africa, call BIssell Consumer services at the numbers below and we will give you the location of a BIssell Authorized service Center in your area. For all other countries, contact your local in country distributor for questions, service, or repair.
-
Page 19: Additional Accessories
3200 203-1297 203-2073 203-2085 3290 3091 203-2445 203-2444 dditional accessories These items are available for purchase as accessories for your BISSELL Lift-Off Multi Cyclonic To purchase call 1-800-237-7691 or visit www.bissell.com. Item Part no. 203-1063 203-1399 203-1099 203-2302 203-6624 203-6625... -
Page 20: Limited One-Year Warranty
*eXCePTIoNs AND eXClUsIoNs identified below, BIssell homecare, Inc., will replace (with new or remanufactured components), at BIssell’s option, free of charge from the date of purchase by the original purchaser, for one year any defective or malfunctioning part do to manufacturers defect.
