Bissell POWEREASE 76R9 Series User Manual

Bissell carpet cleaner user manual
Hide thumbs Also See for POWEREASE 76R9 Series:

Advertisement

Table of Contents

U S E R ' S G U I D E
76R9 SERIES
Safety Instructions
3
Product View
4
Assembly
5
Operation
5-7
Maintenance and Care
8
Troubleshooting
9
Consumer Services
10
Replacement Parts
11
Additional Accessories
11
Warranty
12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWEREASE 76R9 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bissell POWEREASE 76R9 Series

Summary of Contents for Bissell POWEREASE 76R9 Series

  • Page 1 U S E R ’ S G U I D E 76R9 SERIES Safety Instructions Product View Assembly Operation Maintenance and Care Troubleshooting Consumer Services Replacement Parts Additional Accessories Warranty...
  • Page 2 Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance. My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your PowerEase.

  • Page 3: Important Safety Instructions

    ■ Use only manufacturer’s recommended attachments. ■ Use only cleaning products formulated by BIsseLL for use in this appliance to prevent internal component damage. see the Cleaning Fluid section of this guide. ■ Keep openings free of dust, lint, hair, etc.

  • Page 4: Product View

    Removable Nozzle Cleaning fluid Keep plenty of genuine BISSELL 2X Fiber Cleansing Formula whenever it fits your schedule. Always use genuine BISSELL deep cleaning formulas. Non-BISSELL cleaning solutions may harm the machine and will void the warranty. BISSELL BISSELL 2X Fiber 2X Multi-Allergen ™...

  • Page 5: Before You Clean

    Note: Carpeting will dry in three to four hours, depending on carpet style and air circulation in room. A floor fan speeds drying Fill the tank Remove the solution tank by lifting it straight up, then away from the lower body. Unscrew the black cap at the bottom of the solution tank. Fill to the FORMULA line with BISSELL 2X Fiber Cleansing formula. Fill the rest of the tank with hot (not boiling) tap water to the water fill line. Replace and tighten the black cap. Place solution tank on lower body. Rotate Quick Release Cord Wrap™ to release the power cord and plug into an outlet. Pre-Treating Pre-treat stubborn stains and highly soiled carpet in hallways and other high-traffic areas.

  • Page 6: Carpet Cleaning

    peration Carpet cleaning With your foot, press the red power switch [located in foot of unit] With foot, press the detent lever on left side of lower body. Depress spray trigger to spray cleaning solution. Do not overwet. To suction up water, repeat motion over same area without pressing trigger. Repeat steps 3 and 4 until no more dirt can be removed. Continue to clean entire carpet, working in 3’ x 4’ sections. Empty the collection tank when dirty water reaches the full line, or when the solution tank is empty. If floor nozzle stops spraying, turn power switch and check water and cleaning solution levels. Refill if needed. To empty the collection tank Turn power switch from outlet. Remove and empty collection tank. Release collection tank latches [1 each side] by pulling up from bottom of latch and then out. Carefully remove collection tank from lower body by lifting handle. Carry collection tank to a toilet or sink. To empty, pour out contents using opening at back of tank. Rinse collection tank thoroughly. Remove lint and hair from red gasket in base of unit. (Do not remove gasket) Clean nozzle window by lifting latch and removing from machine. Rinse under running water. When finished replace nozzle and secure with latch.

  • Page 7: Hard Floor Cleaning

    Hard floor cleaning (included on select models only) Remove the collection tank (refer to steps 2a and b in the "To empty the collection tank" section on page 6) Attach the hard floor tool by hooking it into the front of the removable nozzle and swinging it down until the tabs pop into place. Replace the collection tank. Be sure to attach the two latches. Fill solution tank with BISSELL 2X Hard Floor Solutions™ to FORMULA fill line. Fill the rest of the tank with hot (not boiling) tap water to the WATER fill line. Replace and tighten the black cap. Follow steps 1-8 in "Carpet Cleaning" section on page 6. w w w . b i s s e l l . c o m WARNING: To reduce the risk of fire and electric shock- when cleaning a hard floor,...

  • Page 8: Machine Storage

    aintenance and care Machine storage Wrap power cord around Quick Release Cord Wrap ™ on side of PowerEase. Wipe all surfaces with a soft cloth. Store cleaner upright in a protected, dry area. NOTE: You may have cleaning solution remaining in the solution tank. You may store your PowerEase this way for the next cleaning task, but never keep soiled solution in the col- lection tank.

  • Page 9: Troubleshooting

    Thank you for selecting a BISSELL product. Please do not return this product to the store For any questions or concerns, BISSELL is happy to be of service. w w w . b i s s e l l . c o m an authorized service representative.
  • Page 10 For information about repairs or replacement parts, or questions about your warranty, call: Or visit the BISSELL website - www.bissell.com when contacting BIsseLL, have model number of unit available. Please record your model number: ___________________ Please record your Purchase Date: ___________________ NOTE: Please keep your original sales receipt.

  • Page 11: Additional Accessories

    34B5 78h6 81T7 4001 To qualify you for discounts, rebates, and other BISSELL perks. w w w . b i s s e l l . c o m Part Name handle assembly solution Tank (Includes Cap and Insert assembly)
  • Page 12 ATTN: Consumer Services BIsseLL homeCaRe, InC. Is noT LIaBLe FoR InCIDenTaL oR ConseQUenTIaL DamaGes oF any naTURe assoCIaTeD wITh The Use oF ThIs PRoDUCT. BIsseLL’s LIaBILITy wILL noT eXCeeD The PURChase PRICe oF The PRoDUCT. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
