Adjustment - Sharp QT-CD111H Service Manual

MECHANISM SECTION
• Driving Force Check
Torque Meter
PLAY: TW-2412 Over 120 g
• Torque Check
Torque Meter
Play: TW-2111 25 to 65 g.cm
Fast Forward: TW-2231 60 to 130 g.cm
Rewind: TW-2231 60 to 130 g.cm
• Head Azimuth
Torque Meter
MTT-114 Output: Speaker Terminal
(CNP201 Load resistance: 8 ohms)
• Tape Speed
Adjusting
Test Specified
Point
Tape
3,000 ± 90 Hz
MTT-111 In motor
TAPE SECTION
Position of each switch or control
Volume control
Function switch
X-BASS
• Bias Oscillation
Adjustment Point Specified Value
82 kHz ± 6 kHz
L301
– 6 kHz
• Playback Amplifier Sensitivity Check
Test Tape Specified Value
1.8 V ± 3 dB
MTT-118
Pin 13 of IC2 Pin 21 of IC2
FET : 2SK19 or 2SK54
D
G
S
10 kohm
Figure 7-1 VCO FREQUENCY TEST CIRCUIT
