SERVICE
Plasma TV
PS51F8500SL
Refer to the service manual in the GSPN (see the rear cover) for more information.
Plasma TV
Chassis
Model Code
MANUAL
1. Precaution
2. Product Specification
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
F5PA
PS51F8500SLXXH
Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS51F8500SLXXH and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung PS51F8500SLXXH

Summary of Contents for Samsung PS51F8500SLXXH

  • Page 1 Plasma TV Chassis F5PA Model Code PS51F8500SLXXH SERVICE MANUAL Plasma TV Contents 1. Precaution 2. Product Specification 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram PS51F8500SL Refer to the service manual in the GSPN (see the rear cover) for more information.

  • Page 2: Table Of Contents

    4.6. AV control code........................4 − 35 Wiring Diagram ..........................5 − 1 5.1. Overall Wiring ........................5 − 1 5.1.1. Pin Connection ......................5 − 3 5.1.2. Connector Functions ....................5 − 8 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 3 Contents 5.1.3. Cables ........................5 − 9 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 4: Precaution

    If the measurement is over 1.0V, unplug the AC power cord and change the polarity before reinserting it. Measure the voltage between the chassis and the ground again. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 5 Critical safety parts should be bracketed with ( ). Use only regular parts for replacements (in particular, flame resistance and dielectric strength specifications). Irregular parts or materials may cause electric shock or fire. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 6: Servicing Precautions

    This is caused by brightness deterioration due to the storage effect of the panel, and to prevent this from happening, we recommend that the brightness and contrast are reduced. (e.g.) Contrast: 25, Brightness: 50 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 7: Static Electricity Precautions

    These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 8: Installation Precautions

    9) When moving a PDP with removable speakers, detach the speakers first before moving the main body. Moving the PDP main body without separating the speakers may cause the speakers to detach, possibly causing damage or injury. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 9: Product Specification

    51" With Stand 23.4 kg Weight (lbs) Without Stand 32.8 kg 64" With Stand 36.3 kg Premium Display Panel Outstanding premium Anynet+ (HDMI-CEC) Feature SMART Interaction Miracast All share (Screen Mirroring / Contents Sharing) Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 10: Feature & Specifications

    Equalizer : 5 band Audio Spec Output Frequency : RF : 20 Hz ~ 15.4 kHz AV/Componet/HDMI : 20 Hz ~ 20 kHz NOTE Dolby Digital +, Game Mode, Film Mode, Energy Saving, Anynet+, 3D Built-In, E-Manual. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 11 1190.5 x 743.5 x 270.0 mm 1482.6 x 918.0 x 320.0 mm With Stand 23.4 kg 36.2 kg Weight 20.9 kg 32.8 kg Without Stand Screen Size 51 inches 64 inches Sound (Output) 10W x 2 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 12: Specifications Analysis

    1 (Cable/Air) - PAL(Air) : EU 1 (Cable/Air) - NTSC (Air) : US, KR O : Supported X : Not Supported NOTE For the power supply and power consumption, refer to the label attached to the product. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 13: Detail Factory Option

    Tuner Auto None Ch Table Front Color ON / OFF P-D-G-Dy O : Supported X : Not Supported NOTE For the power supply and power consumption, refer to the label attached to the product. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 14: Accessories

    Power Cord 3903-000834 Batteries (AAA x 2) 4301-000103 Remote Control AA59-00759A RETURN GUIDE EXIT SMART HUB Component Video BN39-01154C Component Audio BN39-01154H Holder Wire BN61-08951A Cleaning Cloth BN63-01798B Owner`s Instructions BN68-04828G IR Extender Cable BN96-26652A Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 15: Disassembly And Reassembly

    Follow these directions carefully; never use metal instruments to pry apart the cabinet. 3.1.1. Separation of STAND P-BASE Description Description Photo Screw Place monitor face down on cushioned table. Remove screws from the Stand. Remove stand. 6003–000337 M4 * L10 6003–000337 M4 * L10 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 16: Separation Of Assy Cover P-Rear

    Description Photo Screw Remove the screws of rear-cover. 6003–001782 M4 * L12 6003–000337 <51"> M4 * L10 6003–001782 M4 * L12 6003–000337 <64"> M4 * L10 Lift up and remove the rear-cover. <51"> <64"> Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 17: Separation Of Assy Main Board

    F-address buffer to main board (80p-FFC Cable) d) MoIP Camera Cable (20p-FFC Cable) Remove Power Harness - Pull out the cable pushing indicated area. Remove the X-main Harness - Pull out the cable pushing indicated area. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 18 - Pull out the cable pushing indicated area. Remove the screws of main board. CAUTION When you remove Boards, you must disconnect all connectors. If you don't, it can cause problems. 6001–002606 M3 * L10 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 19: Separation Of Smps

    Remove the screws of SMPS 6001–002606 Remove the SMPS M3 * L10 CAUTION When you remove Boards, you must disconnect all connectors. 6003–001439 If you don't, it can cause problems. M3 * L10 6001–002606 M3 * L10 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 20: Separation Of Speaker

    Screw 3.1.5. Separation of SPEAKER Description Description Photo Screw Seperate the speakers (R/L) 3.1.6. Separation of MolP Camera Description Description Photo Screw Remove screw Pull out cable pushing indicated area 6003–001782 M4 * L12 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 21: Separation Of Function/Blutetooth Module/Wifi Module

    M3 * L10 *Seperation of BT module. Remove screw Pull out cable pushing indicated area. 6001–002606 M3 * L10 *Seperation of WIFI module. Remove screw Pull out cable pushing indicated area. 6001–002606 M3 * L10 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 22: Separation Of Bracket Wall/Bracket Module

    3.1.8. Separation of Bracket Wall/Bracket module Description Description Photo Screw Remove screws of the Bracket Wall and Bracket Module. (60", 64") The bracket modules are not existed in 51-inch models 6003–001782 M4 * L12 6003–000337 M4 * L10 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 23: Troubleshooting

    If you do not have Factory remote- control • If you have Factory remote-control Factory b. Move to SVC menu. c. Move to Test Pattern. d. Check inner patterns. (This model only support FBE, READ PRE, READ POST) Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 24: Checkpoints By Error Mode

    Check the internal cable connection status inside the unit. • Major Checklist Check the fuses of each part. • Check the output voltages of the SMPS. • Replace the Main Board. • CN801 CN201_LO Diagnostics CN801 CN201_LO Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 25 PIN1_P S ON : Che ck to s e e if it is 0V Ye s Re pla ce the Ma in Boa rd. CAUTION Make sure to disconnect the power before working on the SMPS board. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 26 Audio is normal but no picture is displayed on the screen. Symptom The output voltage of the Main SMPS. • Major Checklist This may happen when the FFCcable connecting the Main Board and X-Main, Buffer Board • Diagnostics Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 27 Re pla ce the S MP S . Are a ll volta ge ne rma l? Ye s Re pla ce the Ma in Boa rd. CAUTION Make sure to disconnect the power before working on the SMPS board. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 28 When the speaker connectors are disconnected or damaged. • When the sound processing part of the Main Board is not functioning. • Major Checklist Speaker defect. • SMPS not supplying voltage to the main board. • Speaker Connector Diagnostics Speaker Connector Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 29 Ma in boa rd norma l? Ye s S ound Output S ha pe Re pla ce the S pe a ke r. CAUTION Make sure to disconnect the power before working on the IP board. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 30: Operating Logic Led

    LED ON for 5s and LED OFF for 2s ■ Error Code • All error parts are detected by Logic LED • And, [X,Y Driver Fail] and [Logic part Fail] are detected by Front Panel LED Blinking Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 31 • Check the Logic & Main board I2C • Check the logic S/W • Check the PDP Module State 0.5s 1 2 3 4 1 2 3 4 5 1 2 3 4 5 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 32: Blue-Tooth Pairing

    • Press "Pairing Key" on "G.2" glasses for 3ec within 50cm distance from the "Master TV" set. CAUTION 3D glasses in 2010 did not work at 2011 model TV. (Working mechanism is different.) 4-10 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 33: Factory Mode Adjustments

    4.2. Factory Mode Adjustments 4.2.1. Entering Factory Mode To enter ‘Service Mode’ Press the remote-control keys in this sequence. • If you do not have Factory remote-control. • If you have Factory remote-control. Factory Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-11...
  • Page 34 Wired MAC SUCCESS Wireless MAC SUCCESS DRM: Crt 0,Nf /, Wv /, Hc X,Dc /, Mx/,Ml / Factory Data Ver : xxx EERC Version : xxx DTP-BP-HAL-xxxx-xx DTP-BP-MW-xxxx-xx DTP-BP-APP-xxxx-xx POP-FLA-13-xxxx Data of purchase : mm/dd/yyyy 4-12 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 35: Factory Data

    Info Link Server Type development Info Link Country None TTX Group Visual Test Disable MediaPlay DB On with 10MB OPTION_SWU OPTION_SNUM RF Remocon Support CDD mode DPMS Support Num of IPTV CIP Num of CI Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-13...
  • Page 36 Shop Option Shop Mode Exhibition Mode 3D_EmitOn 3D_EmitShowMode 3D GLASS PULSE_S 3D GLASS PULSE_H 3D CUBE Asia Option Unbalance AF Level adjust TX Power Level Mono Last Memory H Shaking Sound High Devi 4-14 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 37 Speaker EQ PEQ Test Amp Model Wall Filter Type SRS Tuning Parm SPDIF PCM Gain AudioDock BT Delay 3D_Glass BT delay Speaker cut-off Freq Audio-IP Test TruBass-Checksum Mic Scale India Sound Speaker Delay Normal Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-15...
  • Page 38 CAM Wait Time TCON_TEMP READ TEMP LAST DCC VERSION DCC CHK SEL DCC CHECK LACAL DCC CHECK TOTAL MulitACC Checksum IIC Bus Stop Tuner Status Voice Debug Power Management HHP option SHOW RM_BIST_DTV RM_BIST_ATV 4-16 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 39 ER Count LOG(View Log) Self Test(for HW) IPERF Stopped OPTION_HDMI DVI/HDMI Auto SOUND HDMI HOT PLUG HOTPLUG Auto SWITCHING HOT PLUG DURATION CLK TERM 300ms DURATION HDMI FLT CNT 100ms HDMI FLT CNT 800ms Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-17...
  • Page 40 NTV RF Region NTV CU FW VER Failure ■ ADC/WB Menu Item Data Remark AV Calibration Comp Calibration PC Calibration HDMI Calibration ADC Result 1st_Y_GH 1st_Y_GL 1st_Cb_BH 1st_Cb_BL 1st_Cr_RH 1st_Cr_RL 2nd_R_L 2nd_G_L 2nd_B_L 4-18 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 41 B-Gain WB_W2_R_Offset WB_W2_B_Offset WB_W2_R_Gain WB_W2_B_Gain WB_N_R_Offset WB_N_B_Offset WB_N_R_Gain WB_N_B_Gain MGA On/OFF R1_Gain G1_Gain B1_Gain R2_Gain G2_Gain B2_Gain R3_Gain G3_Gain B3_Gain R4_Gain G4_Gain B4_Gain R5_Gain G5_Gain B5_Gain R6_Gain G6_Gain B6_Gain R7_Gain G7_Gain B7_Gain R8_Gain Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-19...
  • Page 42 BM_slope BM_start BM_start_max Lfunc_gain Hfunc_gain ACR-Offset Skin-UV FBE Sub color M-Skin-UV M-Sub Color N_Skin_UV N_Sub_Gamma Color Gamut LFUNC_TH1 LFUNC_TH2 LFUNC_TH3 LFUNC_OUT2 LFUNC_OUT3 LFUNC_OUT4 LFUNC_OUT5 UFUNC_TH1 UFUNC_TH2 UFUNC_TH3 UFUNC_OUT2 UFUNC_OUT3 UFUNC_OUT4 UFUNC_OUT5 PPHC_Red PPHC_Green 4-20 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 43 Movie Backlight Movie Gamma M_Sub_Gamma HDMI Black Level SubSetting Gamma 0.95 PWM Max PWM Mid PWM Min Contrast Dimming 7.5 IRE NTSC 7.5 IRE OFFSET 48Hz Enable Peak Dimming Dynamic CE ColorMapping Auto_Red_R Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-21...
  • Page 44 Standard Backlight 3D Contrast 3D Brightness V_3D PWM Delay_60 V_3D ANA Delay_60 V_3D PWM Delay_50 V_3D ANA Delay_50 Motion plus Delay Home Delay Shop Delay CH_VDEC AGC_mode Gain_VCR Y_Gain_Man Y_Shape_sel Y_Shape_SCM C_Shape_sel C_Shape_SCM If_iir 4-22 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 45 SOG_BW SSC_PC RGB_DLY YC_Delay PAL_BG PAL_DK PAL_I PAL_M PAL_N SECAM_BG SECAM_DK SECAM_L NTSC_358 NTSC_443 AV_PAL AV_PAL_M AV_PAL_N AV_SECAM AV_NT358 AV_NT443 AV_PAL60 CH_DP BD_MAX_PERCENT_X BD_MAX_PERCENT_Y BD_DETAIL_AMT_MAX BD_TOUCH_SUPP BD_TOUCH_SUP_INV DR_SIGMA_FIL_GAIN DR_GAIN_IN_ETE SD2HD_Metric Sharpness Pre_GainH1 Pre_GainH2 Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-23...
  • Page 46 Post_GainPE1 Post_GainPE2 Post_GainPV1 Post_GainPV2 CTI_Gain Pre_LTIH LTI_H LTI_V PRE_CORING_H PRE_CORING_V POST_CORING Pre_TOT Post_TOT SH Sub Color Sharpness_LNA S1_Pre_GainH1 S1_Pre_GainH2 S1_Pre_GainH3 S1_Pre_GainV1 S1_Pre_GainV2 S1_Pre_GainV3 S1_Post_GainH1 S1_Post_GainH2 S1_Post_GainH3 S1_Post_GainV1 S1_Post_GainV2 S1_Post_GainV3 S1_Post_GainPE1 S1_Post_GainPE2 S1_Post_GainPV1 S1_Post_GainPV2 4-24 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 47 S2_Pre_GainH2 S2_Pre_GainH3 S2_Pre_GainV1 S2_Pre_GainV2 S2_Pre_GainV3 S2_Post_GainH1 S2_Post_GainH2 S2_Post_GainH3 S2_Post_GainV1 S2_Post_GainV2 S2_Post_GainV3 S2_Post_GainPE1 S2_Post_GainPE2 S2_Post_GainPV1 S2_Post_GainPV2 S3_Pre_GainH1 S3_Pre_GainH2 S3_Pre_GainH3 S3_Pre_GainV1 S3_Pre_GainV2 S3_Pre_GainV3 S3_Post_GainH1 S3_Post_GainH2 S3_Post_GainH3 S3_Post_GainV1 S3_Post_GainV2 S3_Post_GainV3 S3_Post_GainPE1 S3_Post_GainPE2 S3_Post_GainPV1 S3_Post_GainPV2 LNA_Plus Synctip_Noise Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-25...
  • Page 48 2D3D Focus 2D3D Depth1 2D3D Depth2 2D3D Depth3 2D3D Depth4 2D3D Depth5 2D3D Depth6 2D3D Depth7 2D3D Depth8 2D3D Depth9 2D3D Depth10 N240 PWM Delay_60 N240 ANA Delay_60 N240 PWM Delay_50 N240 ANA Delay_50 4-26 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 49 POST_OUT4_ORDER CROSS_PATTERN EnableFB HMVSRMargin_2X_H HMVSRMargin_2X_M HMVSRMargin_2X_L VMVSRMargin_2X HSADPercentT1_2X HSADPercentT2_2X HMVSRMargin_FILM_H HMVSRMargin_FILM_M HMVSRMargin_FILM_L LEDDriver VSYNC_DELAY_3D_50 VSYNC_DELAY_3D_60 FRCQ SSC_OnOff Option SSC_Width SSC_Freq FMD_Demo CSB Vertical CSB Horizontal X_VStabStatVid X_VStabStatF X_VStabCorF X_VStabSensF X_HaloSizStatVid X_HaloSizStatF X_HaloSizCorF X_HaloSizSensF Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-27...
  • Page 50 Hangup Detection Q LVDS Sequence Q LVDS Format Q LVDS bit width PC_Mode_OnOff FRCQ SensD_Film_Low Fallback SensD_Film_Medium SensD_Film_High Rel_Start_Film Rel_Slope_Film H_Len_Start_Film H_Len_Slope_Film V_Len_Start_Film V_Len_Slope_Film SensD_Video Rel_Start_Video Rel_Slope_Video H_Len_Start_Video H_Len_Slope_Video V_Len_Start_Video V_Len_Slope_Video Picture Update 4-28 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 51: Service Adjustment

    Lattice Component IN (Model_#6) Perform in 720p B&W Pattern #24 Lattice PC Analog IN (Model_#21) Perform in VESA XGA (1024x768) B&W Pattern #24 Lattice HDMI IN Perform in 720p B&W Pattern #24 Lattice Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-29...
  • Page 52 6) In “PC Calibration Off” status, press the “ ” key to perform Calibration. 7) When Calibration is complete, it returns to the high-level menu. 8) You can see the change of the “PC Calibration” status from Failure to Success. 4-30 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 53 8) You can see the change of the “HDMI Calibration” status from Failure to Success. ■ White Balance - Adjustment Factory (Low light) (High light) ADC / WB - White Balance Sub Bright Sub Contrast R offset R gain G offset G gain B offset B gain Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-31...

  • Page 54: Software Upgrade

    4.4. Software Upgrade Insert a USB drive containing the firmware upgrade file, downloaded from “www.samsung.com,” into the TV. Please be careful not to disconnect the power or remove the USB drive until upgrades are complete. The TV will be turned off and on automatically after completing the firmware upgrade.
  • Page 55 Off: If you select Off, the TV will notify you with a pop up message when new upgrade software is available. Off, 1 hour later, 2 hours later, 0:00, 2:00, 12:00 or 14:00: The TV will automatically download new upgrade software when it is in Standby mode with the power off. Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-33...

  • Page 56: Rs-232C

    Flow Control : None 2. Description of RS232C Pin# Name Full Name Carrier Detect Received Data Transmitted Data Data Terminal Ready Signal Ground Data Set Ready Request To Send Clear To Send Ring Indicator 4-34 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 57: Av Control Code

    0x03 DVI1 0x06 0x00 DVI2 0x01 DVI3 0x02 Picture Mode Dynamic(Entertain) 0x0b 0x00 0x00 0x00 Standard 0x01 Movie 0x02 Natural 0x03 CAL-NIGHT 0x04 CAL-DAY 0x05 BD Wise 0x06 BackLight 0~20 0x01 0x00 (0~20) Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-35...
  • Page 58 0x00 Flesh Tone -15 ~ 15 0x0e (-15~15) Edge Enhancement 0x0f 0x00 0x01 xvYCC 0x10 0x00 0x01 Motion Lighting 0x11 0x00 0x01 LED Motion Plus 0x07 0x00 On(Normal) 0x01 Cinema 0x02 Ticker 0x03 4-36 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 59 Smart View I 0x06 Smart View II 0x07 Reset Picture Reset Picture 0x0b 0x0b 0x00 0x00 3D Mode 0x0b 0x0c 0x00 0x00 2D->3D 0x01 Side By Side 0x02 Top Bottom 0x03 Line By Line 0x04 Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-37...
  • Page 60 Spanish 0x01 French 0x02 Korean 0x03 Japanese 0x04 Multi-Track Sound Mono 0x05 0x00 0x00 Stereo 0x01 0x02 Auto Volume 0x06 0x00 0x00 Normal 0x01 Night 0x02 TV Speaker 0x07 0x00 0x00 Speaker Select 4-38 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 61 0x00 0x00 the table of below Key value Value 96 (0x60) Down 97 (0x61) Left 101 (0x65) Right 98 (0x62) Menu 26 (0x1A) Internet 147 (0x93) Enter (OK) 104 (0x68) EXIT 45 (0x2D) Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-39...

  • Page 62: Wiring Diagram

    5. Wiring Diagram 5. Wiring Diagram 5.1. Overall Wiring ■ 51" FP Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 63 5. Wiring Diagram ■ 64" FP NOTE The code number of cable (Lead-connector) can be changed, see “Exploded Views and Parts List”. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 64: Pin Connection

    Data_P10 CLK_P2_1 Data_N9 CLK_N3_2 Data_P9 CLK_N1_1 CLK_P3_2 Data_N8 CLK_P1_1 Data_P8 CLK_N2_2 Data_N7 EEPROM_MSDA CLK_P2_2 Data_P7 EEPROM_MSCL Data_N6 EEPROM_WP CLK_N1_2 Data_P6 CLK_P1_2 Data_N5 3.3V STB_2 Data_P5 3.3V CSE_2 Data_N4 3.3V CE_1 Data_P4 3.3V CE_0 Data_N3 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 65 5. Wiring Diagram CN401(MAIN) - CN605(Camera) Pin No. Signal A5V_MOIP_PW A5V_MOIP_PW USB_MOIP_DM USB_MOIP_DP AIT_RESET BCLK LRCLK DATA1 DATA2 CN201_LO(MAIN) - CN801(SMPS) Pin No. Signal STYBY PS_ON D15V D5.3V D5.3V D15V D15V D5.3V D5.3V D5.3V Vs_CON Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 66 51" : CN2011_LO(MAIN) - CN4001(X-Main) 64" : CN2011_LO(MAIN) - CN4001(X-Main) Pin No. Signal 5V_GND 5V_DET DS_RESET DRV_RESET_X 2_VE 51" : CN2012_LO(MAIN) - CN5005(Y-Main) 64" : CN2012_LO(MAIN) - CN5002(Y-Main) Pin No. Signal 5V_DET Y_DS_RESET DRV_RESET_Y 2_VE YSC-CON Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 67 CLK_P3_3 Data_P17 Data_N26 Data_N16 Data_P26 CLK_N2_3 Data_P16 Data_N25 CLK_P2_3 Data_N15 Data_P25 Data_P15 Data_N24 CLK_N1_3 Data_N14 Data_P24 CLK_P1_3 Data_P14 Data_N23 Data_N13 Data_P23 STB_4 Data_P13 Data_N22 CSE_4 Data_N12 Data_P22 CE_2 Data_P12 Data_N21 Data_P21 Data_N20 Data_P20 STB_3 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 68 51" : CN1201(MAIN) - CN4006(X-MAIN) 64" : CN1201(MAIN) - CN4001(X-MAIN) Pin No. Signal DGND DGND REF_SYNC_IN A3.3V_PW BT_SYNC_IN DSCL 3.3V DGND DSDA_3.3V USB_BT_DP KEY_INPUT1 USB_BT_DM KEY_INPUT2 A5V_PW A3.3V_PW WAKE_BT BT_NRESET POWER_DET B5V_USB_IP_WIFI_CI_PW USB_WIFI_DM_HUB2 USB_WIFI_DP_HUB2 DGND Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 69: Connector Functions

    5. Wiring Diagram 5.1.2. Connector Functions Connector Function CN201_LO ↔ CN801 Supply main power and sw_power signal from SMPS to Main Board. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 70 TV Camera 20 Function / POWER 18 Pin Function / WiFi / BT 22 Pin WiFi / BT 22 Pin 51" BN39-01781C 51" BN39-01761D 51" BN96-26671D Code 64" BN39-01781E 64" BN39-01761F 64" BN96-26671F Photo Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 71 E.Asia, W.Asia, https://gspn2.samsungcsportal.com China, Japan N.America, S.America https://gspn3.samsungcsportal.com This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2013 Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under All rights reserved. applicable International and/or domestic law.
