Summary of Contents for HOLLY&MARTIN CK768300TX
- Page 1 68300TX CK768300TX/CK758300TX Baldrick Console For assistance with assembly, contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Page1...
- Page 2 Baldrick Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Baldrick Console Assembly Instructions Screw the Adjustable Levels (3) to the bottom of both Side Metal Frames (B). Rotate the Adjustable Levels (3) clockwise by hand. Figure 1 Attach the Side Metal Frames (D) to Bottom Cross Bars (E) and Shelf Cross Bars (F) assuring the holes for the bolts align.
- Page 4 Attach the Top Metal Frame (C) into grooves on the top of assembled unit as Figure 4 shows. Figure 4 Screw the Bolts (2) to corresponding holes on assembled unit. Tighten by rotating Bolts (2) clockwise with Allen Wrench (1) as shown.
- Page 5 Place Glass Shelf (B) onto the shelf frame as Figure 7 shows. Figure 7 Now your Baldrick Console is ready for use. Caution: • • Tabletop supports up to 40 lb • • Glass shelf supports up to25 lb Figure 8 Page 5...
- Page 6 Parts Replacement Form Page11 Page 4 Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
