- Page 1 HO730300TX Hobbs Desk Holly & Martin® a valued brand of SEI Customer Service 1-800-633-5096 Assembly Instructions service@hollyandmartin.com www.hollyandmartin.com PO#: Page 1...
- Page 2 Hobbs Desk Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing.
- Page 3 Quantity Quantity Quantity of 2 of 2 of 2 Drawer Right Side Panel Drawer Back Panel Drawer Bottom Panel Quantity Quantity Quantity of 19 of 19 of 24 Wood Dowel Cam Bolt Cam Lock Dia. 5/16” x1-1/4” Quantity Quantity Quantity f 12 Bolt Dia.
- Page 4 Hobbs Desk Assembly Instructions Insert Cam Locks (B) into corresponding holes on Cross Panel (6). Screw Cam Bolts (A) into threaded holes Please do not overtighten cam locks. Stop when they feel on Side Panels (2/3) and Middle Panels secure. (4/5).
- Page 5 Page 5 Insert Cam Locks (B) into corresponding holes on pre-assembled unit from Figure Screw Cam Bolts (A) into threaded holes on Top Panel (1). Attach Top Panel (1) to pre-assembled unit from Figure 2 by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
- Page 6 Page 6 Attach Drawer Side Panels (12/13) to Drawer Back Panel (14) using Screws (G). Insert Drawer Bottom Panel (15) into grooves of Panels (12/13/14). Attach Drawer Front Panel (11) to assembled unit using Screws (G). Tighten Bolts and Screws with Phillips screwdriver.
- Page 7 Page 7 Now your Hobbs Desk is ready to use. Figure 7...
- Page 8 Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
