- Page 1 DN744000TX / DN744800TX Driness Drop Leaf Table - White/Gray Driness Drop Leaf Table - Black/Dark Holly & Martin® a valued brand of SEI Weathered Gray Customer Service 1-800-633-5096 service@hollyandmartin.com ASSEMBLY INSTRUCTIONS www.hollyandmartin.com...
- Page 2 Driness Drop Leaf Table Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing any hardware. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the Screw diagrams below.
- Page 3 Driness Drop Leaf Table Assembly Instructions Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page. Attach top metal frame (3) to leg frames (5/6) using short bolts (F) Tighten short bolts (F) with Allen wrench (B).
- Page 4 Attach side top panel (2) to middle top panel (1) using screws (D). Tighten screws (D) using Phillips screwdriver (not included). Figure 3 Connect pre-assembled unit from Figure 2 and pre-assembled unit Figure 3 by inserting long bolts (A) into the five holes of top metal frame (3).
- Page 5 Insert pin stoppers (C) into holes on top panel (1). Note: These pins function as a stopper when top panel is in folded position. Figure5 Screw adjustable levelers (E) into the bottom of the table legs. Note: Adjust each stopper so that the table is stable.
- Page 6 With an assistant, turn the table upright. Now you can enjoy your new Driness Dining Table. Figure 7 Converting to a console: Fold leg frames by hand. Fold top panels by hand. Top panel supports up to 50 lbs. Close leg frame by hand Drop leaf supports up to 15 lbs.
- Page 7 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
