SERVICE
PLASMA DISPLAY TV
PA43H4100AR
Refer to the service manual in the GSPN (see the rear cover) for more information.
PDP TV
Chassis
Model
MANUAL
1. Precautions
2. Product Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
F6CA
PA43H4100AR
Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PA43H4100AR and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung PA43H4100AR

Summary of Contents for Samsung PA43H4100AR

  • Page 1 PDP TV Chassis F6CA Model PA43H4100AR SERVICE MANUAL PLASMA DISPLAY TV Contents 1. Precautions 2. Product Specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram PA43H4100AR Refer to the service manual in the GSPN (see the rear cover) for more information.

  • Page 2: Table Of Contents

    White Balance......................... 4 − 21 4.4.1. Calibration ......................... 4 − 21 4.4.2. Service Adjustment...................... 4 − 22 4.4.3. Adjustment ........................ 4 − 25 Wiring Diagram ..........................5 − 1 5.1. Wiring Diagram........................5 − 1 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 3 Contents 5.2. Pin Connection........................5 − 3 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 4: Precautions

    Do not use an isolation transformer during this test. Use a leakage current tester or a metering system that complies with American National Standards Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL Publication UL1410, 59.7). Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 5: Product Safety Notices

    Product safety is under review continuously and new instructions are issued whenever appropriate. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 6: Servicing Precautions

    AC plug and accessible conductive parts (see above) should be greater than 1 megohm. 6) Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead; always remove the instrument’s ground lead last. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 7: Static Electricity Precautions

    Be sure no power is applied to the chassis or circuit and observe all other safety precautions. 8) Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or lifting your foot from a carpeted floor can generate enough static electricity to damage an ESD. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 8: Installation Precautions

    Do not short circuit, disassemble or overheat the batteries. • Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. • Do not be exposed to excessive heat such as sunshine, fire or the like. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 9: Product Specifications

    1007.4 x 616.2 x 55.7 mm Dimensions 43" (W x H x D) Set with Stand 1007.4 x 670.5 x 261.9 mm Set without Stand 13.6 kg 43" Weight Set with Stand 14.8 kg GVE Model Feature Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 10: Product Specifications

    Auto Volume Leveler Sound Customizer Sound Output (RMS) 10W x 2 Speaker Type Down Firing + Full Range Woofer Smart TV Smart Hub Samsung SMART TV On TV Movies & TV Shows Multimedia Apps News On Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 11 PC In (D-sub) PC/DVI Audio In (Mini Jack) RF In (Terrestrial / Cable input) 1 / 0 Ex-Link ( RS-232C ) IR Out CI Slot Scart MHL CE 3.0 One Connect (Jack) WiFi Direct Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 12 Clock&On/Off Timer Sleep Timer BD Wise Plus Calibration Mode Caption (Subtitle) ConnectShare™ (USB 2.0) Movie AC/DC TV Sports Mode Screen Capture Embeded POP Extended PVR Game Mode History Multiroom Compatible OSD Language Local Language Picture-In-Picture Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 13 Mini Wall Mount Supported Vesa Wall Mount Supported Floor Stand Support TV Camera (Included) IR Extender Cable (Included) Network Speaker (Included) Wireless Keyboard (Included) Wireless LAN Adaptor (Included) User Manual E-Manual ANT-Cable Power Cable Slim Gender Cable Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 14: Feature & Specifications

    ANT - AIR/CABLE IN 75Ω unbalanced AV : 480i/480p COMPONENT : 480i/480p/720p/1080i/1080p VIDEO INPUT HDMI1 : 480p/720p/1080i/1080p HDMI2 : 480p/720p/1080i/1080p AV : 480i/480p AUDIO Input COMPONENT/DVI : 480i/480p/720p/1080i/1080p AUDIO Output AUDIO (L/R) New Features GVE Model Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 15: Specifications Analysis

    Speaker Output 10W + 10W Features Double Screen Caption Still Image My color Control Energy Saving Screen Burn Protection Anynet Connections Antenna 1 (Cable/Air) AV Input 1 Input S-Video Component 1 Input PC (D-SUB) Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 16 2. Product Specifications 1 Input [HDMI 2] HDMI 2 Input 2 (H4100) / 1 (H4000) Sub Woofer Optical Speaker/Stand Built-in Speaker Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 17: Accessories

    Batteries (AAA x 2) 4301-000121 Regulatory Guide BN68-04972B Power Cord 3903-000461 Warranty Card BN68-02497B Image Product Code. No Cable Holder BN61-08370A Input Cables (Sold Separately) Image Product HDMI HDMI-DVI Component Composite (AV) Coaxial (RF) Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 18: Disassembly And Reassembly

    2) Follow these directions carefully; never use metal instruments to pry apart the cabinet. 3.1.1. PDP TV Description Picture Description Screws Place TV face down on cushioned table. Remove 4 screws from the ASSY GUIDE P-STAND. 6003-001782 M4 x L12 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 19 (In this step, two types of screws are used.) • Rear view of 43 HV 6003-001782 M4 x L12 6003-001807 M4 x L10 Remove the ASSY COVER P-REAR. Remove the Power Cables, Speaker Cables and ASSY BOARD P-FUNCTION Cable. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 20 Remove the 4 screws of ASSY PCB MAIN. 6001-002606 M3 x L10 Remove the 5 screws of DC VSS-PDP. 6001-002606 M3 x L10 6003-001439 M4 x L8 Remove the 1 screws of ASSY BOARD P-FUNCTION. 6001-002606 M3 x L10 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 21 Remove the 5 screw of Cover bottom. 6003-001807 M4 x L10 6003-001782 M4 x L12 Remove the 2 screws of the front-cover. Rear view • 6003-001782 M4 x L12 Reassembly procedures are in the reverse order of disassembly procedures. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 22: Troubleshooting

    Module (Panel / Logic) or Main board. H/W Logic test pattern • How to check Logic test pattern? a) Entering Factory mode. b) Move to SVC menu. c) Move to Test Pattern. d) Move to Test Pattern. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 23: Operating Logic Led And Front Cover Led (Ir)

    LED Blink interver is 0.3s and Off time 4s Error Part Operation / Bilink Error Code (Hex) X, Y Driver Fail Temp Protect Logic Board Fail Error Code Detect Module Protection PDP Module Action Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 24: How To Check Fault Symptom

    Check AC power connection. Connect the cable between CN804 and Are the SMPS CN804 and Main CN201 connected? CN201 connector. Is the Fuse (FP801S) of the SMPS Power Replace Fuse (FP801S). Input Part Open? Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 25 PIN #1 : STB5V Replace the SMPS. PIN #2_PS ON : Check to see if it is 0V Replace the Main Board. Make sure to disconnect the power before working on the SMPS board. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 26: No Video

    (Normal : Blink once a second) Check the FFC Cable is it connected correctly? Check/Replace the FFC Cable. Check All output voltages on SMPS. Are Replace the SMPS. all voltages normal? Replace the Main Board. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 27 4. Troubleshooting Make sure to disconnect the power before working on the SMPS board. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 28: No Sound

    Is the cable connection between Main board and Connect the cable properly or replace the the speaker properly connected? cable, if necessary. Is the output voltage of SMPS normal? Replace the SMPS. (CN804 pin #4 : 15VS) Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 29 4. Troubleshooting Is the speaker output terminal of the Main board normal? Replace the Main Board. Replace the Speaker. Make sure to disconnect the power before working on the SMPS board. Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 30: Example Of Trouble Shooting

    Either the main or sub picture does Repace the Main Board. not appear. A green dots appears on the screen. The SMPS voltage is incorrect. Adjust the SMPS voltage according to the • voltage printed on the module label. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 31 4. Troubleshooting Dim screen. X_Main Board defect. Replace the X_Main Board. (blurred in red) • A blank screen appears. Y_Main Board defect. Replace the Y_Main Board. • Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-10...

  • Page 32: Factory Mode Adjustments

    RFS : "NT14L XXXX"K / 2013-XX-XX KERNEL : XXX.XXXX, / Onboot : XXXX NSP-DTVTD-XXXX Model: PA43H4100 Factory data Ver : XXX EERC Version : XXX NSP-BP-HAL-XXXX NSP-AP-CNC-XXXX NSP-AP-MM-XXXX NSP-BP-MW-XXXX NSP-BP-APP-XXXX POP-PNG-XX-XXXX Date of purchase : XX/XX/2013 4-11 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 33: Factory Data

    D AGC PH BW FQ BW PH RATE PD EN PEQ Inx WF Scale Num of Network Stream DP V Size Backend Device ECHO_FS BT_AUDIO_ON_OFF Config_AV_PATH V_HDMI IDENT TYPE 1234 V_HDMI PATH TYPE ABCD Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-12...
  • Page 34 EDID WRITE HDMI1 EDID WRITE HDMI2 EDID WRITE HDMI3 EDID WRITE HDMI4 HDMI EDID Ver HDMI 1.3 HDMI EDID Port NONE EDID WRITE DVI Sub Option RS-232 Jack UART Serial Log on/off Watchdog 4-13 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 35 RTS mode FKP Download 1 FKP Download 2 LMK threshold Low threshold High threshold EEPG Enable PDP Option PIXEL SHIFT TEST LOGIC SW L-51HH-XXXX Panel Temperature LOGIC Waveform Day XX-XX-XX LOGIC CheckSum 0xXXXX Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-14...
  • Page 36 0x00259B76 SubWoofer Support Woofer Type Woofer Volme 0xcbh Woofer Scale 0x8ah Woofer Check Sum NONE Woofer Local Check Sum NONE Amp Local Check Sum NONE Speaker EQ PEQ Test Ready Amp Model NTP7414 4-15 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 37 FRC LVDS SSC MRR FRC LVDS SSC Period FRC LVDS SSC Modulation FRC DDR SSC ON/OFF FRC DDR SSC MFR FRC DDR SSC MRR FRC DDR SSC Period FRC DDR SSC Modulation DDR Margin A CTRL_OFFSET_0_3 Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-16...
  • Page 38 BT UPGRADE BT FREEPAIRING Function Upgrade FRC3D FW Upgrade Camera Upgrade Mic Upgrade JP MICOM UPGRADE DP MICOM UPGRADE Jump Upgrade MIC PROGRAM UPGRADE Smart Hub Reset ER Count WD Count AR Count 4-17 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 39 SCART CVBS Test SCART RGB Test FLASH EEPROM X-TAL Tuner1 Sound AMP HDMI Switch IC USB HUB IC WIFI LVDS T-CON/FRC PCB Test MOIP EcoSensor Voltage Divece Self Test App Self Test EXT Sound Inspection Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-18...
  • Page 40 HDMI Sync HDMI 3D DET HOT PLUG OFF HOLD TIME CAL Data Restore_Copy Expert N/D ADJ ATV IF AGC SPEED ADC/WB ADC Result 1st_Y_GH 1st_Y_GL 1st_Cb_BH 1st_Cb_BL 1st_Cr_RH 1st_Cr_RL 2nd_R_L 2nd_G_L 2nd_B_L 2nd_R_H 2nd_G_H 4-19 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 41 4. Troubleshooting 2nd_B_H MGA On/Off Advanced WB Movie_3D 3D_C_Rgain 3D_C_Bgain 3D_C_Roffset 3D_C_Boffset Picture_3D EPA_3D ColorMapping_3D Sharpness_3D 3D Setting Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-20...

  • Page 42: White Balance

    4. Troubleshooting 4.4. White Balance 4.4.1. Calibration 1) Into the Factory Mode. 2) Select ADC/WB menu. 3) Select ADC menu. 4-21 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 43: Service Adjustment

    Component IN (Model_#6) Perform in 720p B and W Pattern #24 Lattice PC Analog IN (Model_#21) Perform in VESA XGA (1024x768) Lattice HDMI IN Perform in 720p B and W Pattern #24 Lattice Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-22...
  • Page 44 1) Apply the 720p Lattice (N0. 6) pattern signal to the HDMI1/DVI IN port. 2) Press the Source key to switch to “HDMI1” mode. 3) Enter Service mode. 4) Select the “ADC” menu. 5) Select the “HDMI Calibration” menu. 4-23 Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 45 6) In “HDMI Calibration Off” status, press the “►” key to perform Calibration. 7) When Calibration is complete, it returns to the high-level menu. 8) You can see the change of the “HDMI Calibration” status from Failure to Success. Copyright© 1995-2013 SAMSUNG. All rights reserved. 4-24...

  • Page 46: Adjustment

    4. Troubleshooting 4.4.3. Adjustment 1) Into the Factory Mode. 2) Select ADC/WB menu. 3) Select White Balance menu. 4-25 Copyright© 1995-2013 SAMSUNG. All rights reserved.

  • Page 47: Wiring Diagram

    Ma in Bo a r d - B UFFE R F- B UFFE R UN CTI O N p e a k e r ( L) p e a k e r ( R ) Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 48 5. Wiring Diagram POWER Cable (10 Pin) Function Cable (8 Pin) Code Num. BN39-01877B (140 mm) BN39-01759B (120 mm) Photo The code number of cable (Lead-connector) can be changed, see “Exploded Views and Parts List”. Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 49 CN402 (Main Board) ↔ CN1 (Function) Pin No. Signal (Main Board) Pin No. Signal (Function) A3.3V 3.3V MSCL MSDA KEY1 KEY1 KEY1 KEY2 LED_STB CN301 (Main Board) ↔ SPEAKER Pin No. Signal Pin No. Signal R+_OUT L+_OUT R-_OUT L-_OUT Copyright© 1995-2013 SAMSUNG. All rights reserved.
  • Page 50 CIS, Africa E.Asia, W.Asia, https://gspn2.samsungcsportal.com China, Japan N.America, S.America https://gspn3.samsungcsportal.com This Service Manual is a property of Samsung Electronics © 2013 Samsung Electronics Co.,Ltd. Co.,Ltd. All rights reserved. Any unauthorized use of Manual can be punished under Printed in Korea applicable International and/or domestic law.
