- Page 1 SUN2000-(196KTL-H3, 200KTL-H3, 215KTL-H3) Series Quick Guide Issue: 05 Part Number: 31508120 Date: 2021-09-30 HUAWEI TECHNOLOGIES CO., LTD.
-
Page 2: Product Overview
• Before installing the device, read the user manual carefully to get familiar with product information and safety precautions. Huawei shall not be liable for any consequences caused by the violation of the storage, transportation, installation, and operation regulations specified in this document and the user manual. -
Page 3: Mounting Bracket Dimensions
(1) DC input terminals (controlled by DC SWITCH 1) (2) DC switch 1 (DC SWITCH 1) (3) Reset button 1 (RESET 1) (4) DC input terminals (controlled by DC SWITCH 2) (5) DC switch 2 (DC SWITCH 2) (6) Reset button 2 (RESET 2) (7) DC input terminals (controlled by DC SWITCH 3) (8) DC switch 3 (DC SWITCH 3) (9) Reset button 3 (RESET 3) -
Page 4: Installation Requirements
Installation Requirements Installation Angle Installation Space The clearance at the bottom must meet the requirements on the bending radius of the AC output power cable. Installing the SUN2000 • The M12x40 bolt assemblies are delivered with the SUN2000 (bound to the mounting bracket). - Page 5 1. Install the mounting bracket. 2. Unpack the inverter and move it to the specified position. Handles are packed in a fitting bag and are not delivered with the SUN2000. 3. Adjust the installation positions of the handles, and install the SUN2000 on the mounting bracket.
-
Page 6: Installing Cables
Installing Cables Installation Preparations If outdoor copper-core cables are used, select copper wiring terminals. For details about the requirements for cables and terminals of other materials, see the user manual. Item Type Specifications Description PE cable Single-core Conductor cross- • If you choose the outdoor copper sectional area ≥... - Page 7 Item Type Specifications Description AC output Outdoor copper Conductor cross- If you choose the ground • power cable sectional area: 50– point in the maintenance cable [2][3][4] 240 mm compartment for Cable outer diameter: connecting a PE cable, • 24–66 mm (multi- use a four-core cable.
-
Page 8: Installing The Pe Cable
Specifications of the Crimped OT/DT Terminal Specification of the Rubber Baffle Plate Installing the PE Cable • It is recommended that the PE cable be connected to a nearby PE point. Connect the PE points of all SUN2000s in the same PV array to ensure equipotential connections to PE cables. -
Page 9: Opening The Maintenance Compartment Door
Opening the Maintenance Compartment Door • Do not open the host panel of the SUN2000. • Before opening the SUN2000 maintenance compartment door, turn off the downstream AC output switch and three DC switches at the bottom. • Do not open the maintenance compartment door in rainy or snowy days. If you must, take protective measures to prevent rain or snow from entering the maintenance compartment. - Page 10 3. Remove the crimping modules that are bound in the maintenance compartment and save them properly for future use. For some models, a three-hole rubber plug is bound in the maintenance compartment. After removing the rubber plug, save it properly for future use. Crimping module (Optional) Replacing the Crimping Module...
-
Page 11: (Optional) Installing The Solar Tracker Power Cable
Removing the Rubber Rings from the Crimping Module Use scissors to cut off the joints of the rubber rings to remove them. All rubber rings are removed in the same way. (Optional) Installing the Solar Tracker Power Cable 1. A switch-disconnector-fuse or fuse-switch-disconnector with a voltage of no less than 800 V, current of 16 A, and protection type of gM needs to be installed between the SUN2000 and the tracker controller for protection. -
Page 12: Installing Ac Output Power Cables
Installing AC Output Power Cables Remove the corresponding rubber rings in strict accordance with the cable diameter, and ensure • that the crimping module is not damaged. Otherwise the protection level of the solar inverter will be affected. Ensure that AC terminations provide firm and solid electrical connections. Failing to do so may •... - Page 13 Single-Core Cable (five rings) The 32–36 mm cable is supported only (four rings) by some models. Refer to the (three rings) corresponding label to get the (two rings) supported size. (one ring) Bending Radius Multi-Core Cable Single-Core Cable Unarmored Armored Unarmored Armored R ≥...
-
Page 14: Closing The Maintenance Compartment Door
Closing the Maintenance Compartment Door Installing DC Input Power Cables Selecting DC Input Terminals Ensure that the PV module output is well insulated to ground. • The PV1 DC input terminal must be connected to a PV string. • PV1, PV3, PV4, PV6, PV8, PV9, P11, PV13, and PV14 strings are preferentially connected. The SUN2000 has three DC switches (DC SWITCH 1, DC SWITCH 2, and DC SWITCH 3). - Page 15 For example, if the number of input routes is 9–14, the DC input terminals are selected as follows. Number of Terminal Selection Number of Terminal Selection PV Strings PV Strings PV1, PV3, PV4, PV6, PV8, PV9, PV1, PV2, PV3, PV4, PV6, PV8, PV9, PV11, PV13 and PV14 PV11, PV13 and PV14 PV1, PV2, PV3, PV4, PV5, PV6,...
-
Page 16: Installing The Rs485 Communications Cable
Installing a DC Input Power Cable Connector connection: Installing the RS485 Communications Cable 4.10 Communication Port Pin Definition When routing communications cables, separate communications cables from power cables to prevent communication from being affected. - Page 17 Port Definition Definition Description RS485A IN, RS485 RS485A OUT, RS485 Used for cascading differential signal+ differential signal+ inverters or connecting to RS485-1 devices such as the RS485B, RS485 RS485B, RS485 SmartLogger. differential signal– differential signal– PE, shielding ground PE, shielding ground RS485A, RS485 RS485B, RS485 Used for connecting to...
-
Page 18: Verifying The Installation
Connecting Communications Cables (4–8 mm Two-Hole Rubber Plug) If three communications cables are to be connected, use the three-hole rubber plug that is bound in the maintenance compartment. Verifying the Installation 1. The SUN2000 is installed correctly and securely. 2. The DC switches and downstream AC switch are OFF. 3. -
Page 19: Powering On The System
When powering on the system, you must switch on DC SWITCH 1 first, and then switch on DC SWITCH 2 and DC SWITCH 3 after LED 1 is steady on. Huawei shall not be held liable for damages caused by failing to follow this sequence. - Page 20 Display Category Indicator Status Description Grid connection LED2 LED4 indication Steady green The SUN2000 has connected to the power grid. Blinking green Steady at short An environmental fault occurs at AC side. intervals The SUN2000 does not connect to the power grid. Communications LED3 indication...
- Page 21 The app is named SUN2000. Scan the QR 2. Go to Huawei app store (https://appstore.huawei.com), search for SUN2000, and download the app installation package. You can also scan code to the QR code (https://appgallery.cloud.huawei.com/appdl/C10279542) to download download the installation package.
- Page 22 Function Menu • The screenshots in this document correspond to app version 3.2.00.013 (this app is available only on Android phones currently). • When the WLAN connection is used, the initial name of the WLAN WLAN module SN hotspot is Adapter- , and the initial password is Changeme.
-
Page 23: Customer Service Contact
Customer Service Contact Region Country Phone Service Support Email France Germany Spain eu_inverter_support@huawei.com 0080033888888 Europe Italy Netherlands Other countries For details, see solar.huawei.com. Australia eu_inverter_support@huawei.com 1800046639 Turkey eu_inverter_support@huawei.com 0080021686868 Malaysia /1800220036 (+66) 26542662 (charged apsupport@huawei.com Asia Pacific by local call) Thailand... - Page 24 Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China solar.huawei.com...
