Gray Kneeling Chair with Back Support
Instruction Manual
SKU: DN-CH-K02G
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/collections/chairs/products/dn-ch-k02b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@idragonn.com
www.idragonn.com
Chat live with an agent!
309-278-5303
