Black Kneeling Chair with Back Support
Instruction Manual
SKU: DN-CH-K02B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://idragonn.com/collections/products/products/ergonom-
ic-kneeling-chair-with-back-support-adjustable-stool-for-home-
and-office-improve-your-posture-with-an-angled-seat-thick-com-
fortable-cushions-black
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@idragonn.com
www.idragonn.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DRAGONN DN-CH-K02B
Summary of Contents for DRAGONN DN-CH-K02B
- Page 1 Black Kneeling Chair with Back Support Instruction Manual SKU: DN-CH-K02B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://idragonn.com/collections/products/products/ergonom- ic-kneeling-chair-with-back-support-adjustable-stool-for-home- and-office-improve-your-posture-with-an-angled-seat-thick-com- fortable-cushions-black GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@idragonn.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Insert upper frame (D) into lower frame (E) and align front holes to one of three positions, depending on the user leg length. Assemble frames using the long sleeve nut (N) with x2 M6x12 screws (F) and tighten using the Allen wrench (O). STEP 2 Assemble adjustable support (Q) to rear of upper frame (D) using medium sleeve nut (M) with x2 M6x12 screws (F) and tighten using the Allen wrench (O). - Page 4 STEP 3 Connect adjustable support (Q) to rear of lower frame (E) using short sleeve nut (L) with x2 M6x12 screws (F) and tighten using the Allen wrench (O). STEP 4 Assemble seat pad (A) to rear of upper frame (D) using x3 M6x20 pan head screws (G), and knee pad to front of lower frame (E) using M6x40 screws (H).
- Page 5 STEP 5 Press fit casters (J, K) into holes on underside of the frames. STEP 6 Assemble grip handles (R) to seat pad (A) using M6x20 screws (I).
- Page 6 STEP 7 Insert end of back seat support (S) into slots in back seat hinge (U), then place cover on the hinge. STEP 8 Secure back seat support (S) with back seat hinge and cover (U) to back seat pad (C) using M6x25 screws (T). Tighten with the Allen wrench (O).
- Page 7 STEP 9 Attach back seat assembly to seat pad (A) using x3 M6x20 pan head screws (G). Tighten with the Allen wrench (O). STEP 10 Adjust seat height and angle by turning the knob on the adjustable support (Q).
- Page 8 We are happy to replace parts to ensure you have a fully functioning product. help@idragonn.com www.idragonn.com 309-278-5303 Chat live with an agent! FOR MORE DRAGONN PRODUCTS, CHECK OUT OUR WEBSITE AT: www.idragonn.com...
