- Page 1 LightStack™ UHD Plug and Play Fiber Enclosure Instructions TOOL Note: Protruding installation is not compatible with Front Cable Manager Front Cable Manager...
- Page 2 LightStack™ UHD Plug and Play Fiber Enclosure Instructions Protection tape(4 places) Do not remove the protection tape before Front Cable Manager is securely attached and the mounting screws have been tightened. (see step 3) Mounting holes for Front Cable Manager Note: The edge of Front Cable Manager should align with the edge of Enclosure.
- Page 3 Enclosure Instructions Use push-pull feature to remove jumper Use a 3 party extraction tool to remove jumper Use with Siemon LC BladePatch Jumpers Use with Siemon FJ2/J2 LC Jumpers Remove front door by pulling out the latches on both sides, allowing full access to LC ports in the front of the panel.
- Page 4 C. Never install this device in a wet location. D. Never install wiring during a lightning storm. Rear Cable Management Global Headquarters Watertown, Connecticut USA www.siemon.com Tel: (1) 866-548-5814 For a complete listing of our global offices visit our web site...
