Homelegance 1524-9 Assembly Instructions

Thank you for purchasing this product. Please take time to read and follow the instructions below. Check that you have all parts and
hardware before assembly. Parts apparently missing are often found in the packing materials. If you do not have all the parts listed,
have your dealer contact us and they will be sent to you immediately.
It is recommended to install protective pads under all legs and supports to avoid damage or
scratches when placing furniture on a wood floor or other hard surface, and to limit
indentation and prevent discoloration if placing on carpet.
PART LISTS / LISTE DE PIECES
NO COMPONENT
A CHEST
B BUN FOOT / PIED
A
MADE IN MALAYSIA
NOTE : MUST TIGHTEN SCREWS PERIODICALLY
ASSEMBLY INSTRUCTIONS /
INSTRUCTION D' ASSEMBLAGE
NO
QTY
SKETCH
1
1
SPRING WASHER/ RONDELLE D'
2
3
FLAT WASHER/ RONDELLE PLATE
4
4
Hardware Pack
B
WITH USE SCREW WILL BECOME LOOSE CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
DESCRIPTION SKETCH
JCBC BOLT/
BOULON
ARR T
4
4x
1
2
3
B
QTY
SIZE
4
M6 x 100MM
PCS
4
1/4" x
2mm(Thickness)
PCS
4
1/4" ID x 13mm x
1mm(Thickness)
PCS
1 PC
M4 x 110mm
Remark : Turn the Chest
to upright position as shown.
Soft Surface
PAGE 1 OF 2 /
PAGE 1 DE 2
