AIR CURTAIN
User Manual
Models:
TAC9004RC
TAC12004RC
TAC9005RC
TAC12005RC
TAC18005RC
IMPORTANT NOTE:
Thank you for selecting a TECO quality Air Conditioner.
Read this manual carefully before installing or operating
your new air conditioning unit. Make sure to save this
manual for future reference.
The design and specifications are subject to change
without prior notice for product improvement. Consult
with the sales agency or manufacturer for details.
Advertisement
Table of Contents
Related Manuals for TECO TAC9004RC
Summary of Contents for TECO TAC9004RC
- Page 1 TAC9005RC TAC12005RC TAC18005RC IMPORTANT NOTE: Thank you for selecting a TECO quality Air Conditioner. Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference. The design and specifications are subject to change without prior notice for product improvement.
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ..................2 OUTLINES AND DIMENSIONS ................3 INSTALLATION ..................... 4 WIRING DIAGRAM ....................6 SPECIFICATIONS ....................6 AIR FLOW ADJUSTMENTS .................. 7 AIR DISTRIBUTION CHART ................. 7 CLEANING AND MAINTENANCE ................. 8 REPAIRS, SERVICE & WARRANTY ..............8... -
Page 3: Safety Precautions
Use the correct power socket. Make the connections securely so that any force to the power cord is not applied to the power socket. • Always use the correct motor, capacitor, switch, and other accessories specified by TECO. • When moving and reinstalling the air curtain, consult the dealer or an authorised technician •... -
Page 4: Outlines And Dimensions
(Picture 1). When it is installed, the position must be accurate and be reliable, the method of installation to be as follows: The external dimensions and install the size (mm): Model TAC9004RC TAC12004RC 1200 TAC9005RC... -
Page 5: Installation
INSTALLATION Fix on the concretes wall (1) According to the different specification is to be gives the mounting dimensions, chose the position (picture 2) (2) Splits out explodes bolt's hole which matches M8 to pull on the position, will pull explodes the bolt to fix on the concretes wall, simultaneously should protect bolt's swinging radius is 15mm. - Page 6 Installation Precaution When installing the air curtain, please note the following, can increases the efficiency of air curtain. 1. Please install on the solid place, prevents the work from vibration, prevents noise which vibration to be produces. 2. Please install the air curtain on the inside of the room. 3.
-
Page 7: Wiring Diagram
Wind Noise Size ation Voltage Frequency height Power Flow Speed (dB) (kg) (mm) WxHxD (mm) (Hz) (mm) Model (m³/h) (m/s) TAC9004RC 1020 14.5 ≤44 16.0 900×230×212 960×290×270 3.5-4.5 TAC12004RC 1360 14.5 ≤45 19.5 1200×230×212 1260×290×270 3.5-4.5 TAC9005RC 1260 18.0 ≤46 16.5... -
Page 8: Air Flow Adjustments
AIR FLOW ADJUSTMENTS The air deflector of air curtain is adjustable. The air direction changed depends to the air defector. (Picture 7) Picture 7 AIR DISTRIBUTION CHART... -
Page 9: Cleaning And Maintenance
Only an Authorized Service Person can carry out servicing or repairs to this appliance. IF SERVICE IS REQUIRED: If you have any difficulties with your product, please contact: TECO Australia’s Service on 1300 660 037 (8:30am - 4pm Monday ~ Friday AEST) For warranty details please visit www.teco.com.au... - Page 10 GBJ-V1...
