SUPPLEMENTAL INSTRUCTIONS
HEATER INSTALLATION GUIDE
FOR
TR30
TR60

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Seachill TR30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TECO Seachill TR30

  • Page 1 SUPPLEMENTAL INSTRUCTIONS HEATER INSTALLATION GUIDE TR30 TR60...
  • Page 2 Safety Teco chillers are designed and built with safety as a prime consideration; industry-accepted safety factors have been used in the design. Each chiller is inspected at the factory for safety and operation. Any necessary adjustments are made before shipment. Follow the maintenance schedules outlined in this manual for optimum performance and safe operation.
  • Page 3 Contact Us North American distributor : TECO US Service: service@tecous.com Sales: sales@tecous.com www.tecous.com...
  • Page 4 STEP 1 Turn off and unplug the chiller. Remove screws from housing. Slide housing about 8" (20cm) back. Unplug green ground wire from housing. Slide the housing off. Keep the plastic washers that come with the housing screws, these prevent chipping of the housing powder coat.
  • Page 5 STEP 2 Unscrew and remove ring nut over Heater port. Use cloth to cover the plastic ring nut to prevent damage from pliers. Remove plug and o-ring from ring nut. Place o-ring over the top of the Heater and push down approximately 3/4 inch to 1 inch onto the Heater.
  • Page 6 STEP 3 Pull the heater plug through the hole in the frame. Connect two pin adapter on wiring harness to one of the available two pin connectors mounted on top of support strut. HEATER INSTALLATION GUIDE...
  • Page 7 STEP 4 Plug in and turn on the chiller Find the circuit board on the top of the electronic housing. Remove the plastic “jumper” from prongs 4 and 5 (See Diagram Below). Place jumper on pins 7&8, this will reset your chiller. Remove jumper from pins 7&8.

This manual is also suitable for:

Seachill tr60
