Installation
manual
towel warmer
Model OD-0910
SPECIFICATION
Voltage: AC120V
Rated power: 100 W (OD-0910-SS, OD-0910-BR) 135 W (OD-0910-MB)
Unit size: 870 X 530 mm
This towel warmer is intended for the use in bathrooms or laundry areas. Read the instruc-
tions carefully before operating.
1
8
Please read the wall-mounted instal-
lation carefully to understand how to
install on your ideal location of the
wall.
Please use the services of a certified
electrician for the apparent wireless
installation of this product.
Make sure to complete the installa-
tion before using it.
Frequency: 60Hz
3+1
3+1
Plug the power cord into an electrical
outlet for the apparent wire installa-
tion.
Switch ON/OFF : Press button ON/
OFF, product will start to work, if you
want to stop it, press the button
again.
Hardwire installation
4
8
84.00 mm
115.00 mm
The timer can be adjusted to 2 h
(hour) or 4 h (hour). Press the button
to select the right time.
Please turn it off and take the plug
C:\dessin classé compagnie\Odass\round tube.asm
out from the outlet if you are not
using it.
70.00 mm
bolt
2
1
wire hole
1
92.00 mm
TOLERANCES
SAUF CONTRE INDICATION, LES
DIMENSIONS SONT EN POUCES.
NOM
1/X
± 1/16"
± .01"
round tube ASM.dft
.XX
± .003"
.XXX
DESSINÉ PAR
.XXXX
± .0005"
± 1°
ANGLE
CLIENT
125
FINI DE SURFACE :
PAGE
PROJECTION :
1
#6-32 screw
0.75" long
Asn Machinerie inc
CE DOCUMENT EST LA
82 St-Joseph Sud
Asn
PROPRIÉTÉ DE
Rivière-Bleue qc
Machinerie inc
IL NE DOIT
Canada G0L-2B0
PAS ÊTRE DÉVOILÉ, UTILISÉ
tel:418-893-5844
fax:418-893-2858
OU REPRODUIT EN TOUT OU
EN PARTIES SANS
cell:418-714-1829
L'AUTORISATION ÉCRITE DE .
alain@asnmachinerie.com
Asn Machinerie inc
www.asnmachinerie.com
DATE DESSINÉE
Client
21-02-2020
emplacement
ÉCHELLE
REV
1 de 1
N/A
Advertisement
Table of Contents
Related Manuals for odass OD-0910
Summary of Contents for odass OD-0910
- Page 1 SPECIFICATION Voltage: AC120V Frequency: 60Hz Rated power: 100 W (OD-0910-SS, OD-0910-BR) 135 W (OD-0910-MB) Unit size: 870 X 530 mm This towel warmer is intended for the use in bathrooms or laundry areas. Read the instruc- tions carefully before operating.
- Page 2 Plug-in installation instruction 1. Identify the location of the holes needed for the screws on the wall. 2. Drill holes in the wall. 3. Insert screw anchor into the holes. 4. Rivet the base onto the nut with 5. Install the base with the screw. the fixing screw.
- Page 3 Hardwire installation instruction 1. Identify the location of the holes needed for the screws on the wall. 2. Drill holes in the wall. 3. Insert screw anchor into the holes. 4. Cut the supply cable. Make sure to keep enough wire to go through the tube and to plug into the junction box.
- Page 4 9. Install the base with the 10. Press the button to turn it screws. on or off, select on the timer 2 or 4 hours.
- Page 5 LIMITED WARRANTIES sentation or warranty other than those contained the owner/end-user, contractor or builder.Odass Odass warrants the product to be free from defects in the warranty; any affirmation, repre-sentation or warrants for a period of 10 years, shower doors to in workmanship from the date of purchase.
