6) Main PCA and FFC connectors.
T-10
Above: PCA shield
7) CMWP PCA.
5 x T-5 screws
8) Reel motor PCAs.
Remove the tape
reel
EL-MF877-00
Template Revision A
T-10
PCA > 10 square cm's
CMWP PCA > 10 square cm
Both reel motor PCAs > 10 square
cm
