- Page 1 Envent Engineering Ltd. Hydrogen Sulfide Analyzer Model 330S & 331S Model 330SDS & 331SDS ANUAL Revision 2.6 19 Nov 2021...
-
Page 3: Table Of Contents
Dual Sensor Analysis cycle (SDS): ......................... 7 .............................. 8 NALYZER PECIFICATIONS INSTALLATION ..............................10 ................................. 10 NPACKING 3.1.1 Standard spare parts for 330S H S analyzers: ....................10 3.1.2 Standard spare parts for 331S H S analyzers: ....................11 ..............................11 EQUIREMENTS ............................12... - Page 4 Figure 3. Space Requirements for the 330S & 331S H S Analyzers ................ 13 Figure 4. 331S Recommended Venting for 331S (Same for 330S model) .............. 15 Figure 5. AO 4-20 mA Output Wiring Options ......................17 Figure 6. Sample Chamber (Exploded View) ......................18 Figure 7.
-
Page 5: Introduction
S analysis in liquids or the addition of a hydrogen reaction furnace for total sulfur measurements. This document will be referring to models 330S and 331S. However, the information applies equally to the 330SDS and 3301SDS (Dual sensor), unless otherwise stated. To clarify, the difference between an "S"... -
Page 6: Disclaimer
An extended warranty may be available with certified start-up. Contact Envent Engineering Ltd for details. Envent Engineering Ltd reserves the right to change the product design and specifications at any time without prior notice. 1.22 Disclaimer No other warranty is expressed or implied. -
Page 7: Key Symbols
Caution: hot surface. Indicates additional information intended to help clarify an earlier statement or to aid in the reader’s understanding of a given topic. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 3... -
Page 8: Equipment Overview
→ COOH The electronics built into the models 330S and 331S have been programmed to measure the rate of darkening over time which, in turn, gives the hydrogen sulfide concentration level. When no H S is in contact with the H S sensing tape, the analyzer sensor reads 1000 mV (+/- 100 mV). -
Page 9: Analysis Cycles
S sensing tape is measured in analysis cycles. An analysis Cycle lasts up to a maximum of 720 seconds (12 minutes). Do not change the Maximum Analysis Time, consult Envent Engineering Ltd. Analyzers sold prior to Mid-August 2016 are set to have a 360 second analysis cycle. - Page 10 However, RRA values can be used as a trigger alarms setpoint in case the application requires a rapid response time (less than the RRA Analysis completion). The first part of the RRA Analysis (2) to (3) Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 6...
-
Page 11: Dual Sensor Analysis Cycle (Sds)
(Analog output 4-20 mA, alarms, display H2S value, etc.). Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 7... -
Page 12: Analyzer Specifications
Battery (for 1d Controller Board only): Lithium 3.6V, Dia 0.571'' & 0.992'' Long Electrical 330S-DS Class I, Division 1 Groups B C D T3C Tamb 0 °C to + 50 °C Certification 331S-DS Class I, Division 2 Groups B C D T3C Tamb 0 °C to + 50 °C For more information on Hazardous location certification, refer to the Envent’s Website. -
Page 13: Table 1. 330S/331S H2S Analyzer Specifications
Board Ethernet Port Utilized for TCP/IP communication capabilities Auto Calibration Utilized to initiate a calibration based on time of day or manually Table 1. 330S/331S H2S Analyzer Specifications Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 9... -
Page 14: Installation
Upon arrival, the packaging should be immediately inspected for any external damage that may have occurred during shipping. If any damage is present, please contact Envent Engineering Ltd and request that the carrier's agent be present when the analyzer is unpacked. If a disagreement arises, the incoterms agreed to by the seller and the customer will overrule any dispute. -
Page 15: Standard Spare Parts For 331S H S Analyzers
The model 330S & 330SDS are designed for cETLus Class 1, Division 1, Groups BCD, Temp Code T3C (Tamb 0°C to 50°C). These models are designed for indoor use only. Ensure that the analyzer received is suitable for the electrical classification of the installation site. -
Page 16: Mounting Requirements
This unit requires a disconnect device rated 240 VDC and 5A max. It must be protected by a circuit breaker rated 240 VDC and 5A max, and it is to be installed in accordance with local electrical codes. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 12... -
Page 17: Space Requirements
3.3.1 Space Requirements Figure 3. Space Requirements for the 330S & 331S H S Analyzers Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 13... -
Page 18: Sample Point Selection
Make sure to leave at least 1 foot of extra space on the left side of the 330S H S analyzer. This will allow proper opening of the side door located at the upper blue chassis where the H S sensing tape is located. -
Page 19: Sample Volume & Flow Rate
Figure 4. 331S Recommended Venting for 331S (Same for 330S model) 3.3.5 Sample Volume & Flow Rate The sample should be supplied to the 330S/331S H S analyzer at 10-15 psig and at a flow of 83.63 cc/min (set flowmeter at 2.0). A bypass sweep is recommended to reduce sample lag time in the... -
Page 20: Installation Of Analyzer Components
3.3.6 Installation of Analyzer Components In this section, the description and installation of the main components of the 330S & 331S H analyzers are covered. Total Sulfur and Dilution system options are not covered in this section. Please refer to Total Sulfur and Dilution manuals. -
Page 21: Figure 5. Ao 4-20 Ma Output Wiring Options
Figure 5. AO 4-20 mA Output Wiring Options Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 17... -
Page 22: Figure 6. Sample Chamber (Exploded View)
Figure 6. The window keeps a clear view for the LED and the photodiode to work properly and isolates them from the sample gas. The rubber gasket seals the Sample Chamber compartment preventing any leaks. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 18... -
Page 23: Table 3. Aperture Strips & Ranges
H S Sensing tape. Envent Engineering Ltd offers a unique design of humidifiers meant to meet the Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6... -
Page 24: Figure 7. Envent's Humidifier Unit For 330S & 331S
S sensing tape; refer to Figure 7 . Figure 7. Envent's Humidifier Unit for 330S & 331S The humidifier works by using Nafion Tubing. This material has the capability to transports water vapor from the most humidified medium to the driest medium. The sample gas traveling inside the Nafion tube is dryer than the outside of the tube, which is being saturated with water, thus, humidifying the gas sample. -
Page 25: Figure 8. Humidifier Unit Installed In A 331S H S Analyzer
(exhaust fan). The eductor will eliminate any influence on the analyzer reading; refer to Figure 9. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 21... -
Page 26: Figure 9. Eductor Block (Venturi Effect)
15 psig pressure being expelled through the restricted fitting creating suction from the gas vent line (Venturi Effect). DO NOT block the opening at the bottom of the eductor or the modified elbow fitting. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 22... -
Page 27: Operation & Configuration
6. Turn on the sample gas flow to the conditioning sample system and then open the sample inlet valve. 7. Open the sweep valve slightly and adjust pressure regulator to 15 psig and the flow meter to 2.0. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 23... -
Page 28: Analyzer Display Interface
The display is made up of a Graphic Display, four (4) pushbuttons and (8) LED's. Refer to Figure 10. Figure 10. 330S Display (left) & 331S Display (right) The Descriptions and Function of the display buttons and LED's are described in table Table 4 & Table... -
Page 29: Calibration Procedure
S analyzer should be calibrated. It will depend on the application, importance of accuracy for the application, and how dirty or clean the environment and sample are. The following is the calibration procedure for the 330S/331S H analyzer: Source a calibration gas of H S in balance of N2 regulated to 15 psi (check expiry date). - Page 30 S alarm set points. Remove the analyzer from bypass mode by pressing the bypass button. Verify the "Bypass" LED turns off. Alarms are armed after removing the bypass mode. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 26...
-
Page 31: Re-Zero Sensor Procedure
S alarm set points. 12. Remove the analyzer from bypass mode by pressing the bypass button. Verify the "Bypass" LED turns off. Alarms are armed after removing the bypass mode. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 27... -
Page 32: Maintenance
Incorrect configuration of the analyzer may cause incorrect operation. Injury and/or damage to facilities may occur. Check analyzer's functionality after configuration changes have been made. Disassembly of the pressure regulator and solenoids in the field is not advised. Consult Envent Engineering Ltd if the regulator or solenoid appears contaminated. -
Page 33: H 2 S Sensing Tape Change Procedure
S sensing tape is replaced. Replace the filter(s) as required. S Sensing Tape Change Procedure Figure 11. 331S & 331SDS Sensing Tape Change Procedure (Same as the 330S & 330SDS models) Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 29... -
Page 34: Sample Conditioning System Cleaning Procedure
Sample Conditioning System Cleaning Procedure During start-up or plant upset situations, the 330S/331S H S analyzer may become contaminated with amine or hydrogen sulfide scavenger solution. This may cause the analyzer to read low (this can be determined at calibration). If the analyzer reads low, it will require incremental increases in the gain to maintain calibration. - Page 35 5. Once sample conditioning system has been re-assembled, apply calibration gas to the analyzer. Refer to "H S Gas Calibration” on page 25. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 31...
-
Page 36: Troubleshooting
Re-zero sensor block if necessary. Refer to "Re-zero Sensor procedure" on page 26. Regulator not maintaining 15 Replace Regulator, Consult Envent psig (Changing flow rate to Engineering Ltd. analyzer) Continued on next page Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 32... - Page 37 S Gas Calibration" on page 25. Contact Envent Engineering Ltd to order aperture (if applicable) and for assistance to install new aperture and re-calibrate analyzer. Continued on next page Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 33...
- Page 38 +/- 2%. If necessary, do a gas calibration. Refer to "H S Gas Calibration" on page 25. Continued on next page Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 34...
- Page 39 This will activate the motor and move the H2S Sensing tape for a few seconds. Tape breaking High liquid content in sample Genie probe and additional filtration may be required in sample conditioning system. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 35...
- Page 40 If so, refer to "Aperture Strip" on page 19 for aperture size and "H2S Gas Calibration" on page 25. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 36...
- Page 41 Sensor/ sensor wire failure Re-zero the sensor block. Refer to "Re-zero Sensor procedure" on page 26. If procedure fails, sensor or sensor wire may require replacement. Continued on next page Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 37...
- Page 42 Oven failed and temperature has dropped below the optimal temperature. Please consult Envent Engineering Ltd. Blank Display Contrast needs adjustment Change contrast by turning the potentiometer in the display board. Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 38...
- Page 43 If AO boards were not requested, an external power supply must be used. Refer to "Analog Outputs" on page 16 to see different wiring options. Continued on next page Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 39...
- Page 44 Problems with the (50 psi) Heated regulator may be required if liquid sample pre-regulator at the hydrocarbon carry over is present at the pre- sample point. regulation sample. Continued on next page Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 40...
- Page 45 It is recommended that 25% from calibration gas used is close in value to where original gain the alarm setpoint values need to be (for after calibration more accuracy). Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 41...
-
Page 46: Appendix A - Recommended Spare Parts List
13'' Chubby Quartz Tube (Total Sulfur option only) 3300429 TS Ceramic Heater (Total Sulfur option only) 330431 Kalrez O-rings (Total Sulfur option only) 330900 Tubing, Cleaner, Fittings Maintenance Kit Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 42... -
Page 47: Appendix B - Sealing Compound Information
APPENDIX B – SEALING COMPOUND INFORMATION Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 43... - Page 48 Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 44...
- Page 49 Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 45...
-
Page 50: Appendix C - Safety Data Sheet For H S Sensing Tape
APPENDIX C – SAFETY DATA SHEET FOR H S SENSING TAPE Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 46... - Page 51 Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 47...
- Page 52 Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 48...
- Page 53 Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 49...
- Page 54 Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 50...
-
Page 55: Appendix D - Risk Assessment - Safety Information
> Rapid unconsciousness, cessation of breathing, and death 700 ppm and > Immediate loss of consciousness above > Permanent brain damage and death in a few minutes even if removed to fresh air at once Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 51... -
Page 56: Table 7. Hydrogen Sulfide Quantities & Health Effects
(if applicable), safety glasses, hand protection, steel toed boots. Depending on the location of the H2S analyzer, appropriate breathing device might be required such as SCBA (Self-contained Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 52... - Page 57 Not immediate If the analyzer is flooding, the analyzer Sample system & safety and health needs to be immediately isolated, analyzer concern turned off and cleaned. Refer to Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 53...
- Page 58 Certification nameplate must be cleaned only with a damp cloth to prevent static charging hazard which could result in an explosion Table 8. Risk Assessment Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 54...
-
Page 59: Contact Us
Toll Free: 1 (877) 936 – 8368 Tel: (403) 253-4012 Fax: (403) 253 -4016 Email: info@enventengineering.com Tel: 1 (713) 567 – 4421 China Tel: 86 (138) 0119 – 1148 Envent Engineering Ltd. H2S Analyzer User’s Manual – Revision 2.6 Page 55...
