When doors are closed, feed between INPUT1 (terminal 5) and EXGND (terminal 6 =
GND/common reference) a voltage coming from door relay where:
0 Vac/dc = lift DOOR OPEN.
+12/24Vdc (9/18 Vac) = lift DOOR CLOSED.
In case of black out, send cabin to lowest floor and reconnect the 699Plus control unit again
to the power supply. 699Plus will automatically re-check and activate the compensation
function.
+
