SERVICE MANUAL
MODEL
CD-XP120W Mini Component System consisting of CD-XP120W
(main unit) and CP-XP120 (speaker system).
CONTENTS
SHARP CORPORATION
MINI COMPONENT SYSTEM
CD-XP120W
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
CD-XP120W
No. S7254CDXP120W
Page

Advertisement

Table of Contents
loading

Related Manuals for Sharp CD-XP120W

Summary of Contents for Sharp CD-XP120W

  • Page 1: Table Of Contents

    MINI COMPONENT SYSTEM CD-XP120W MODEL CD-XP120W Mini Component System consisting of CD-XP120W (main unit) and CP-XP120 (speaker system). • In the interests of user-safety the set should be restored to its original condition and only parts identical to those specified be used.
