COUNTERTOP KIT MULTIFRUIT

ASSEMBLY INSTRUCTIONS

1
CHECK THAT YOU HAVE RECEIVED ALL THE MATERIAL
CORRECTLY:
2
1
INSTRUCTIONS
1 INSTRUCTIONS
2 COUNTERTOP KIT MULTIFRUIT
3

FIT THE COUNTERTOP BIN ACCORDING TO THE FIGURE.

Zumex Group, S.A.
Zumex USA & Canada
Tel: +34 961 301 251 · Fax +34 961 301 255 · zumex@zumex.com · Zumex Service Tel: +34 960 800 999 ·
Tel: 1 305 591 0061 · zumexusa@zumex.com · Zumex Service Tel: 1-877-ZUMEX-TA (1 877 986 3982)
2
MAKE HOLES IN THE COUNTER TO FIT THE PARTS
ACCORDING TO DRAWING.
4
POSITION THE MACHINE OVER THE CURVE OF THE
COUNTERTOP BIN AS SHOWN IN THE PICTURE.
