9. Specifications

Applicable Standards: ±1dB high accuracy meets Class 2 standards (IEC 61672-2013 and
ANSI/ASA S1.4/Part 1), IEC 61260-1: 2014 Class 2, ANSI S1.11: 2004 Class 2, ANSI S1.43:
1997 Type 2
Measurement functions: Simultaneous measurement of main channel and sub channel.
Frequency weighting and time weighting are set independently for main and sub channel.
Sound level meter mode: All-pass processing for the measurement items listed below is
carried out separately for the main channel and sub channel
Analyzer mode: For the main channel, octave, octave 1/3 or simultaneous octave, 1/3
octave band real-time processing and all-pass processing are carried out.
For the sub channel, only all-pass processing is carried out.
Processing types in each operation mode
Channel
AP/OCT
Frequency
Sound
weighting
level meter
Time weighting
mode
Measurement
values
AP/OCT
Frequency
weighting
Analyzer
mode
Time weighting
Measurement
values
Measurement time: 1 to 59 seconds, 1 to 59 minutes, 1 to 24 hours
Microphone: ½ inch electret condenser type (Free field)
Display: Backlit color TFT LCD (320×240 dot matrix)
Update frequency: 100ms
Accuracy: ±1.0dB (ref 94dB @1kHz)
Measurement Frequency range: Octave analysis 31.5 Hz to 8 kHz; 1/3 Octave analysis 25 Hz to 10kHz
Frequency weighting:
Inherent noise: A-weighting max. 17dB; C-weighting max. 25dB; z-weighting max. 30dB
GlobalTestSupply
www. www.
Main
AP
A/C/Z
F/S/10ms/I
Lp, Leq, SEL, Lmax, Lmin, L Lp, Leq, SEL, Lmax, Lmin, L
N
AP, OCT
A/C/Z
F/S/10ms/I
Lp, Leq, SEL, Lmax, Lmin, L Lp, Leq, SEL, Lmax, Lmin, L
N
407790A-EN_V2.4 1/20
50
information@itm.com
.com .com
Sub
AP
A/C/Z
F/S/10ms/I
N
AP
A/C/Z
F/S/10ms/I
N
