3.6 Comparator Output Operation
The comparator output is an open collector output that can be used to control external
equipment.
1. Press the button to enter the menu list screen.
-
+
2. Use the / buttons
ON/OFF setting.
-
+
3. Press the / buttons
-
+
4. Press the buttons again to select 1). Comparator Level
then press button. (Setting range 25 to 130dB, 1 - dB steps)
5. Follow the above steps to select 2). Comparator Band
press button
6. Press the button to return to the measurement screen.
