ROMAN TUB FAUCET
MODELS
40-BV2-CNCH-B – Chrome
40-BV2-CNBN-B – Brushed nickel
40-BV2-CNBB-B – Brushed bronze
PACKAGE AND HARDWARE CONTENTS
PART
DESCRIPTION
A
Spout assembly
B
Hot handle assembly
C
Cold handle assembly
D
SAFETY INFORMATION
Please read and understand this entire manual before attempting to
assemble, operate or install the product.
WARNING
• Protect your eyes with safety glasses when cutting or soldering water
supply lines.
PREPARATION
Before beginning assembly of product, make sure all parts are present.
Compare parts with package contents list and hardware contents. If any
part is missing or damaged, do not attempt to assemble the product.
Contact customer service for replacement parts.
Estimated Assembly Time: 60 minutes
Tools Required for Assembly (not included): Adjustable Wrench, thread
sealant tape, Silicone
Need Help? Please call our toll-free line at (877) 319-3757 (8 am to 5 pm CST) for additional assistance or service.
Homewerks Worldwide, LLC • Lake Bluff, IL 60044 • www.homewerksww.com
QUANTITY
Hose
1
1
1
2
CAUTION
• If you solder the joints during installation, the seats, cartridges, and
washers must be removed before using a flame or the warranty will
be voided on these parts.
• Cover the drain to avoid losing parts.
Installations may vary depending on how the previous faucet was
installed. Supplies necessary for the installation of the faucet are not
all included; however, they are available wherever plumbing supplies
are sold.
Prior to beginning installation, turn off the hot and cold water lines, then
turn on the old faucet to release built-up pressure. When installing the
new faucet, hand tighten the connector nuts. DO NOT OVERTIGHTEN.
Connections that are too tight will reduce the integrity of the system.
A
B
D
ADA
C
08-01-2018
