Installation Considerations
Qt X 300/600 systems
• Output runs must have the same device type (Standard or Active Emitters)
and will share the same sound masking settings. The cabling runs must
be configured to prevent any signal interference among the 4 channels
along the layout. (Refer to illustrations
• Differences in ceiling height of more than 6" (152mm) need to be
connected as separate outputs because sound masking levels will be
different.
• Each output's sound masking levels can be individually controlled and
then assigned to networked zones with additional controls applied to the
whole zone.
Cable Cabling Type
Cat 3, 5, 5e, 6 - 4-pair (8-conductor)
Signal Cable 24 AWG Solid CMP
(EIA/TIA 568B standard termination)
Cat 3, 5, 5e, 6 - 4-pair (8-conductor)
Powered
24 AWG Solid CMP
Signal Cable
(EIA/TIA 568B standard termination)
14 AWG,
Power Cable
2-conductor Stranded CMP
Maximum Number
of Standard or Active
Emitters
(Qt X 300/600)
** Signal Length = 1000 ft (304.8m) Longest "Powered Signal" length
page 4
pages 16-17).
Qt Passive emitter
(Max Distance from Qt X)
1000 ft (304.8 m) from Controller
to last emitter
—
—
Qty 60 per Output run (A or B)
—
Qty 120 per Output total (A+B)
Installation and Operation Guide
Qt Active Emitter
(Max Distance from Qt X)
**1000 ft (304.8 m) from Controller to last
emitter of the longest pathway
(including the powered signal cable length)
400 ft (121.9 m)
from Injector Output to last Active Emitter
400 ft (121.9 m)
from Power Supply to Injector Input
Qty 25 per Injector Output
Qty 50 per Injector
Qty 100 per paired (A/B) outputs - requires
2 Injectors
