Biamp cambridge Qt 300 Demo Kit Quick Start Manual

Software Demo
Operations Screen
• Modify tab: Show the ability to change settings
• Emitter settings for Qt Standard or Active
• Commissioning (example: ramping, time of day)
• Equalizer
• Review tab: shows that changes are saved and summarized
• Administration tab: shows that the following screens exist:
• Service contact information
• Networking and security
• Error alerts
• Zone names
Paging and/or Music Demo
• Music: smartphone, PC, iPod, CD Player
• Paging: PBX, paging microphone
Room Control Demo
• Room control is currently only connected to Qt Standard Emitters
(Zone 1)
cambridgesound.com
Qt and QtPro are either trademarks or registered trademarks of Biamp Systems, LLC in the United States and other countries.
Other product names referenced may be trademarks or registered marks of their respective owners and Biamp Systems is not
affiliated with or sponsored by these companies. All specifications are subject to change.
Visit cambridgesound.com for the latest specification information.
Qt 300 Demo Kit
800.218.8199
PN 1000560 Rev B
Qt
300 Demo Kit
®
This kit demonstrates sound masking, office paging and
background music.
Qt Standard Emitters | Qt Active Emitters
Demo Kit:
F. Audio cable with headphone
A. Qt 300 Control Module
B. Qt Standard Emitter (x2)
G. 1/8" stereo input
Qt Active Emitter (x2)
H. Qt 300 power cable
C. Contact Closure Switch
I. Ethernet cable*
D. Qt Room Control
J. Qt 300 Demo Kit Manual
E. Power Injector
*For PC Internet connection
jacks
