NewAge Products Pro Series Assembly Instructions

Hide thumbs Also See for Pro Series:

Install InstructIons

Assembly Instructions for NewAge Pro Series Racking

Parts List

Please read completely through the instructions and verify that all parts

listed are present before beginning assembly.

C-Wire Deck (3-ea.) L1810mm*W564mm

6 x Bolts

6 x Screws

, www.newageProducts.com

need more information

try

NewAge Products

(40101)

A-Upright Frame (2-ea.) L1829mm*W610mm

B-Cross Beam (6-ea.) L1892mm

E-Tie Bar (3-ea.)

D-Channel Bar (12-ea.) L559mm

1 877 306 8930

for answers to commonly asked questions

Table of Contents

Do you have a question about the Pro Series and is the answer not in the manual?

Page 1 Install InstructIons NewAge Products Assembly Instructions for NewAge Pro Series Racking (40101) Parts List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A-Upright Frame (2-ea.) L1829mm*W610mm B-Cross Beam (6-ea.) L1892mm C-Wire Deck (3-ea.) L1810mm*W564mm D-Channel Bar (12-ea.) L559mm...
Page 2 Products Inc. Panel and accessory warranty 10 year limited manufacturer warranty Tools Required Rubber Mallet or Hammer. LOAD CLAIMS Loading Capacity per shelf – 1000 lbs Maximum Concentrated Load – 800 lbs Total Loading Capacity – 3000 lbs Caution 1.
Page 3 Products Inc. Panel and accessory warranty 10 year limited manufacturer warranty 5. Repeat steps 2 through 4 to attach next set of Cross Beams (part B) at the same level to form the second shelf frame, as shown in detail Note: The columns are adjustable in 3"...
Page 4 Products Inc. Panel and accessory warranty 10 year limited manufacturer warranty 7. Use Tie Bar (part E) to connect and support the Cross Beam (part B) with Bolt and Screw. Pick up one Channel (part D) and fix i t t o t h e a s s e m b l e d u n i t a s shown in detail #4.
Page 5 Products Inc. Panel and accessory warranty 10 year limited manufacturer warranty 9. Periodically inspect the unit to ensure beams are seated properly and brackets are firmly connected to the Columns. , www.newageProducts.com 1 877 306 8930 need more information...
