Homelegance 5803RF-24 Assembly Instruction

PARTS LIST

No Sketch
1
2
3
4
5
6
7
NOTE : YOU WILL ALSO NEED A PHILIP SCREWDRIVER (NOT PROVIDED).
MADE IN MALAYSIA
ASSEMBLY INSTRUCTION
ITEM NO : 5803RF - 24
Thank you for purchasing the product. Please take time to read and follow the instruction below.
Check that you have all parts and hordware before assembly. Parts apparently missing are often
found in the packing materials. If you do not have all the parts listed, have your dealer contact us
and they will be sent to you immediately.
It is recommended to install protective pads under all legs and supports to avoid damage or scratches
when placing furniture on a wood floor or other hard surcafe, and to limit indentation and prevent
discoloration if placing on carpet.
Description Quantity
1PC
Chair Back
1PC 1PC
Seat Frame
LSF Front Leg 1PC
1PC
RSF Front Leg
1PC
LSF Cross Bar
1PC
RSF Cross Bar
1PC
Front Cross Bar
DO NOT TIGHTEN BOLTS UNTIL COMPLETELY ASSEMBLED.
COUNTER HEIGHT CHAIR
Description
No
JCBC
A
- M6 x 1.0 x 70mm
JCBC
B
- M6 x1.0 x 60mm
JCBC
C
- M6 x 1.0 x 35mm
Spring Washer
D
- 1/4" x 1/4" x 1/2" x 0.06"
Flat Washer
E
- 1/4" x 2/7" x 3/4" x 0.04"
Pan Head Screw
F
- #8 x 1 1/2" x 3.0
Allen Key
G
- 1/6" x 2"
* HAREWARE ARE SET IS IN 5803RF-24 FOR ASSEMBLY.

HARDWARE LIST

Sketch
Quantity
4PCS
4PCS
2PCS
10PCS
10PCS
6PCS
1PC
