RoboMaster ESC Center Board 2 User Manual page 3

2. Make sure to use the product in strict accordance with the specifications
listed in this document. Failure to do so may reduce the product service life
or even lead to permanent damage.
3. To avoid physical damage, make sure to assemble the center board correctly.
4. DO NOT open the silicone case. Otherwise, foreign objects may fall inside
and short circuit the center board.
5. Insert the rubber plug to prevent foreign objects from entering the center
board and causing a short circuit when the power port is out of use.
Introduction
The RoboMaster ESC Center Board 2 is a highly integrable expansion board
that consists of multiple power output ports and CAN bus ports, which can
provide power to several components at the same time. The center board
boasts a compact design, while the new silicone case improves reliability.
Interface Description
2
2
2
2
1
5 4
2
2
2
2
3
3
3
